Pfaff 3307-1 SERIES - Balance Wheel; Adjusting the Button Clamp (Only on Subclass -1;.)

Controls
7 - 2
7.03 Balance wheel
● By pressing and holding down balance
wheel 1, it is possible to adjust the
needle bar manually.
7.04 Adjusting the button clamp (only on subclass -1/.).
● After loosening T-screw 1, with sliding
bar 2 the button clamp is adjusted to
match the button size, see Chapter 9.05
Adjusting the button clamp to the
button size.
1
0
4
-0
0
4
1
Fig. 7 - 04
2
Fig. 7 - 03
1
