Pfaff 421E1 - Stop Positions

Adjustment
13.05.13 Stop positions
Requirement
The machine must
1. be 4 mm before the BDC of the needle bar when sewing is interrupted and
2. position itself at the TDC of the needle bar after thread trimming.
● Turn the machine off.
● Select INPUT mode.
● Select the input menu function (number key 5).
● Select the SERVICE function.
● Select the SEWING MOTOR function.
● Select the ADJUST POSITIONS function.
● Select the function BOTTOM POSITION or TOP POSITION.
● Input the values which correspond to the requirements.
5
2
2
2
1
or
13 - 35
