Pfaff 421E1 - Example for Programming a Decorative Seam

Programming
11 - 29
Fig. 11 - 57
1 2
3
4 5 6 7 9 0
Enter
8
Esc
Clear
1 2
3
4 5 6 7 9 0
Enter
8
Esc
Clear
# 1
NO. OF STITCHES 0
6
Enter
0
2
Enter
# 1
NO. OF STITCHES 0
11.15.02 Example for programming a decorative seam
The decorative seam to be sewn should have:
- four seam sections
- and be saved with the comment „Deco 1“
- at program number 6
● Select INPUT mode.
● Select the programming function.
● Enter the program number.
● Confirm this entry with the Enter key.
● Enter comment (see chapter 11.15.01 Example for programming a seam).
● Confirm with the Enter key.
● Program the first seam section.
This seam section should have
- stitch counting (1 stitch)
- and a stitch length of 2 mm.
● Select the stitch length function (number key 4).
● Enter the stitch length (see chapter 11.15.01 Example of seam programming).
● Confirm with the Enter key.
● Select the seam section end function.
Enter
Fig. 11 - 56
