Controls
Fig. 7 - 01
7 Controls
7.01 On/off switch
● Turn the machine on/off by turning
On/Off switch 1.
Fig. 7 - 02
7.02 Keys on the machine head
● Different functions are triggered by
pressing the different keys.
Key 1: reverse sewing
Key 2: sews one stitch with half stitch
length.
Key 3: sews one stitch with full stitch
length.
0
1
7 - 1
2
1 1
1
2
3
