Adjustment
13 - 10
● Loosen screws 5.
● Bring the needle bar to 1.8 after BDC.
● Place the adjustment pin (Part no. 61-111 641-39) into hole 6 and place under pressure.
● Position the hook point at the middle of the needle and tighten screws 5.
● Set the needle height in accordance with requirement 2.
● Remove the adjustment pin from hole 6.
● Align needle guard 4 in accordance with requirement 3 by turning the eccentric 7
(screw 8).
Screws 3 remain loosened for further adjustments.
