Installation and commissioning
20
8.01.02 Setting up the PFAFF 8310-042 and the PFAFF 8310-043
If the machine is delivered without a table, be sure that the frame and the table
top which you intend to use can hold the weight of the machine and the motor.
It must be ensured that the supporting structure is sufficiently sturdy, even du-
ring sewing operations.
The method of packaging used requires that the table top be lowered for trans-
port. The following is a description of how to adjust the height of the table top.
Fig. 8 - 02
Loosen screws 1 and 2 and set the desired table-top height
Tighten screws 1 well.
Adjust the position of the pedal so that you can operate it comfortably and tighten
screw 2.
●
●
●
1
1
2
2
