Care and Maintenance
65
12.05 Changing the lamps (only on flat-bed version)
Fig. 12 - 04
1
Switch off the machine and let it cool down!
Danger of burns when touching the sonotrode!
Do not touch the glass section of the new halogen lamps with bare fingers!
Switch off the machine.
Detach cover 1.
Remove the halogen lamp located under the cover from its socket and replace it with a
new lamp of the same type (12 V, 5 W).
Replace cover 1.
●
●
●
●
