Pfaff 8310-041

Adjustment
80
HW Term SW Term Function
EIN 17 X10/2 Generator frequency
13.12.03 Analog Outputs
HW Term SW Term Function Remark
Top roller X33 DC-Motor 2 Top roller motor (slave) DC-Motor
Bottom roller X34 DC-Motor 1 Bottom roller motor
(master)
DC-Motor
X23 RDRUCKOUT Roller pressure set value Pressure re-
gulating val-
ve
X22 PAMPLOUT Standard power amplitude Ultrasonic
generator
13.12.04 Analog Inputs
HW Term SW Term Function
AE2 X19/2 RDRUCKIN Roller pressure regulator actual value control
AE1 Pedal X14/8 Pedal Analog pedal
AE3 X16 Amplitude Generator signal
AE4 X17 Power Generator signal
