9 Preparation
All regulations and notes in this Service Manual must be observed!
Special attention must be paid to the safety regulations!
All setting-up work must only be carried out by personnel with the appropriate
training!
9.01 Adjusting the roller clearance
Fig. 9 - 01
Sonotrode 3 and roller 4 must never have direct contact!
Danger of serious damage to the machine!
Switch on the machine.
Lower the top roller.
Loosen clamping screw 1.
Adjust the roller clearance to match the workpiece and sealing application with
adjustment wheel 2, see Chapter 7.04 Adjustment wheel for the roller clearance.
Tighten clamping screw 1.
●
●
●
●
●
1
2
3
4
