Pfaff EcoDrive P40 ED User Manual

P40 ED Input
39
Group Parameter Description Machine type User level Setting range Set value
7
703* Thread take-up lever position raised 1, 3
2
4, 5
B
B
B
0 - 255
0 - 255
0 - 255
236
230
226
705* End of cutting signal 1, 2, 5
3
4
B
B
B
0 - 255
0 - 255
0 - 255
200
140
100
706* Start of cutting signal 1, 5
2
3
4
B
B
B
B
0 - 255
0 - 255
0 - 255
0 - 255
136
15
100
80
707* Start thread tension release 1, 3, 4, 5
2
B
B
0 - 255
0 - 255
164
195
710* Needle position raised 1, 2
3
4, 5
B
B
B
0 - 255
0 - 255
0 - 255
184
206
212
715 Switch-on time [ms] for thread wiper 1, 2, 3, 4, 5 B 0 - 2000 60
718 Stop brake tacting
( 0 = brake off)
1, 2, 3
4, 5
B
B
0 - 100
0 - 100
0
7
719 Tacting output (presser foot)
100 = 100 % starting
1, 2, 3
4, 5
B
-
10 - 60
-
0
-
721 Tacting output (feed adjustment)
100 = 100 % starting
1, 2, 3, 4, 5 B 10 - 90 40
722 Acceleration ramp for sewing motor
1 = fl at, 50 = steep
1, 2, 3
4, 5
B
B
1 - 60
1 - 60
50
30
723 Brake ramp for sewing motor
1 = fl at, 50 = steep
1, 2, 3
4, 5
B
B
1 - 60
1 - 60
40
27
729 Start delay after lowering presser
foot [ms]
1
2, 3, 4, 5
B
B
10 - 2000
10 - 2000
20
120
730 Lift delay for presser foot at end of
seam
1
2, 3, 4, 5
B
B
0 - 2000
0 - 2000
0
50
734 Tacting output(cutting magnetic) 1, 4, 5
2
3
B
B
B
0 - 90
0 - 90
0 - 90
10
40
80
* = These parameters remain unchanged when the set parameter values are reset,
see Chapter 10.01 Reset / Cold start.
