Input P40 ED
42
Group
Parameter
Description
Machine type
User level
Setting range
Set value
8
815 Motor starting method after mains on
1 = sinus method,
2 = impulse method
1, 2, 3, 4, 5 C 1 - 2 1
880 Max. starting current [A] 1, 2, 3
4, 5
C
C
1 - 10
1 - 10
5
8
884 Proportional amplifi cation of speed
control of sewing motor
1, 5
2
3
4
B
B
B
B
3 - 24
3 - 30
3 - 24
3 - 24
9
16
10
6
885 Integral amplifi cation of speed control
of sewing motor
1, 2, 3
4, 5,
C
C
10 - 80
10 - 80
50
23
886 Proportional amplifi cation of positioning
controller(sewing motor)
1, 2, 3, 4, 5 C 1 - 15 8
887 Differential amplifi cation of positioning
controller(sewing motor)
1, 2, 3, 4, 5 C 1 - 15 8
889 Time for positioning control in [ms],
0 = always
1, 2, 3, 4, 5 C 0 - 2500 200
890 Proportional amplifi cation of stop brake 1, 2, 3, 4, 5 C 1 - 25 8
897* MINI-motor variant
1 = long, 0 = short
1, 3, 4, 5
2
C
C
0 - 1
0 - 1
0
1
898 Motor current limitation
ON = 15A, OFF = 10A
1, 2, 3, 4, 5 C ON - OFF OFF
9
900 Proportional amplifi cation of speed
controller during trimming
1
2, 3
4
5
B
B
B
B
1 - 24
1 - 30
1 - 24
1 - 24
10
16
6
9
901 Trimming release-speed 1, 2, 3, 4, 5 B 30 - 500 300
933 Switchover of display on screen
ON = diagnosis display
OFF = standard display
1, 2, 3, 4, 5 C ON - OFF OFF
* = These parameters remain unchanged when the set parameter values are reset,
see Chapter 10.01 Reset / Cold start.
