PHILIPS 4000 and 3000 05 SERVICE MODE
14/18
PresstheEspressobuttontomoveBUtowork
Action by user LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
When the BU reaches the work position the Led NoBeans
is switched on
ON NA NA NA
ERROR: Led NoBeans remains off, Check the work mi-
croswitch(broken?),theBUmotor(blocked?)andthewi-
ring(JP16).
NA NA NA NA
ERROR: led GenAlarm Switch ON; the absorbed current
is much more 300mA (with BU) or 200mA (without BU)
check the BU and the motor
NA NA ON NA
Press the Coffee button to move BU to home
Action by user LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
When the BU reaches the home position the Led NoBeans
is switched on
ON NA NA NA
ERROR: Led NoBeans remains off, Check the work mi-
croswitch(broken?),theBUmotor(blocked?)andthewi-
ring(JP16).
NA NA NA NA
ERROR: led GenAlarm Switch ON; the absorbed current
is much more 300mA (with BU) or 200mA (without BU)
check the BU and the motor
NA NA ON NA
Finish condition:WithBU,DragDrawer,
door closed
LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
OFF OFF OFF OFF
Level 4 (Pump)
Start condition:BUnotinserted,Dragdrawerand
servicedoorclosed,nowatersensor
LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
OFF OFF OFF OFF
If the Dreg drawer is not inserted or the Service door is
not closed the EV cannot be opened and test cannot be
performed.Ifthese2inputsarenotintherightposition,
Led Dreg drawer full will be RED
NA NA NA ON
Start condition:NOBU,Dragdrawer,door
Closed and No Water sensor
LED INDICATION
Led
NoBeans
Led
NoWater
Led
GenAlarm
Led Dreg
drawer full
OFF OFF OFF OFF
If the Dreg drawer is not inserted or the Service door is
not closed the BU test cannot be performed. If these 2
inputsarenotintherightposition,LedDregdrawerfull
will be RED
NA NA NA ON
Level 3 (Brewing unit)
Press BUTTON Stand-By to move to the next screen
Press BUTTON Stand-By to move to the next screen
