Alignments
EN 147BJ2.4U/BJ2.5U LA 8.
8.4.2 Dealer Options
Table 8-3 Dealer options
8.4.3 (Service) Options
Select the sub menu's to set the initialization codes (options) of
the set via text menus.
Table 8-4 Service options
8.4.4 Opt. No. (Option numbers)
Select this sub menu to set all options at once (expressed in
two long strings of numbers).
An option number (or "option byte") represents a number of
different options. When you change these numbers directly,
you can set all options very quickly. All options are controlled
via eight option numbers.
When the NVM is replaced, all options will require resetting. To
be certain that the factory settings are reproduced exactly, you
must set both option number lines. You can find the correct
option numbers on a sticker inside the TV set.
Example: The options sticker gives the following option
numbers:
• 04368 00005 01066 08707
• 00000 00032 00512 00000
The first line (group 1) indicates hardware options 1 to 4, the
second line (group 2) indicates software options 5 to 8.
Every 5-digit number represents 16 bits (so the maximum value
will be 65536 if all options are set).
When all the correct options are set, the sum of the decimal
values of each Option Byte (OB) will give the option number.
See next table for the option overview.
Menu item Subjects Options Description
Personal Options Picture Mute On Picture mute active in case no picture detected
Off Noise in case of no picture detected
Virgin Mode On TV starts up (once) with a language selection menu after the Mains switch is turned "on" for
the first time (virgin mode)
Off TV does not start up (once) with a language selection menu after the Mains switch is turned
"on" for the first time (virgin mode)
Menu-item Subjects Options Description
PIP/DS Dual Screen None / 1 tuner / 2 tuners no DS / DS with one tuner / DS with two tuners
Data TV Guide US On / Off Feature present / not present
Display Screen “Value” Used screen size, type, and resolution
Scanning Backlight On / Off Feature present / not present
Dimming Backlight On / Off Feature present / not present
Video Repro Picture Processing Spider / No Spider Feature present / not present
Combfilter None / 2D / 3D Only selectable when Columbus is present
Ambient Light None / Mono / Stereo Inverter not present / one inverter / two inverters
MOP On / Off Feature present / not present; in this chassis, no MOP is implemented
Source Selection HDMI 1 None / Audio / No Audio No HDMI / HDMI with analog audio / HDMI without analog audio
HDMI 2 None / Audio / No Audio No HDMI / HDMI with analog audio / HDMI without analog audio
USB version None / 1.1 / 2.0 + CR No USB / USB 1.1 in side I/O panel / USB 2.0 in cardreader panel
IEEE1394 Yes / No Connector present / not present
Ethernet Yes / No Connector present / not present
S/PDIF inputs None / 1 conn. / 2 conn. None / 1 connector present (in)/ 2 connectors present (in/out)
Audio Repro Subw. Internal Present Yes / No Internal sub woofer present / not present
Acoustic System
(Cabinet design, used for
setting dynamic audio
parameters).
None n.a.
Entry ME5 5W n.a
Entry ME5 15W 42/50PF7320A
(Soft) Wrap n.a.
Top n.a.
Entry+ 42/50PF9630A, 50PF9830A
Others n.a.
Miscellaneous Alternative Tuner Philips / Alps Tuner brand
Tuner Type TD1336S Tuner type
Opt. no. Group 1 xxxxx xxxxx xxxxx xxxxx (see set sticker)
Group 2 xxxxx xxxxx xxxxx xxxxx (see set sticker)
