Figure 5-2 Display option code overview
Note: Be very careful which display option code you choose,
make sure it’s the original one (“Screen Diversity” on the option
code sticker).In case the wrong display option code is used the
TV can start rebooting.
• Store. All options and alignments are stored when
pressing “cursor right” and then the “OK”-button
• SW Maintenance.
– SW Events. Not useful for service purposes. In case of
specific software problems, the development
department can ask for this info.
– HW Events. Not useful for service purposes. In case of
specific software problems, the development
department can ask for this info.
How to Navigate
• In SAM, you can select the menu items with the “CURSOR
UP/DOWN” key on the RC-transmitter. The selected item
will be highlighted. When not all menu items fit on the
screen, move the “CURSOR UP/DOWN” key to display the
next/previous menu items.
• With the “CURSOR LEFT/RIGHT” keys, it is possible to:
– (De) activate the selected menu item.
– (De) activate the selected submenu.
How to Exit SAM
Use one of the following methods:
• Press the “MENU” button on the RC-transmitter.
• Switch the set to STAND-BY via the RC-transmitter.
Note: As long as SAM is activated, it is not possible to change
a channel. This could hamper the White Point alignments
because you cannot choose your channel/frequency any more.
Workaround: after you have sent the RC code “062596 INFO”
you will see the service-warning screen, and in this stage it is
still possible to change the channel (so before pressing the
“OK” button).
E_06532_030.eps
220606
Code nr Dimming
Nr of bit
PWM
analog Full Baby
0 PDP SDI 42 768p 1024 V3_SA42AX-****-Rev,2
2 PDP FHP 42 1024i 1024 A1-FPF42C128128UC-52-v01 NA 10 (8)
3 LCD LPL 30 768p 1280
LC300W01-A3P7-v2.1 analog 8
4 LCD LPL 37 768p 1366
LC370W01-A6K1-v1.0 analog 8
X
5 LCD LPL 42 768p 1366
LC420W02-A6-v1.0 analog 8
X
ASV1-LQ315T3LZ13
ASV2.2
7 PDP SDI V3 42 480p 852
V3_S42SD-YD05-v0.2 NA 8
8 PDP FHP 37 1024i 1024
A1_PFP37C128128UB-71-
v0.1
NA 10
10 LCD AUO 30 768p 1280
T296XW01-v0.5 analog 8
11 LCD LPL 32 768p 1366
LC32CW01-A6K1v1.0 analog 8
X
12 LCD AUO 32 768p 1366
T315XW01V0-v0.1 PWM 8
ASV2_LQ370T3LZ21
ASV2.2LQ370T3LZ44
13 LCD Sharp 37 768p 1366
Asv2.3 (1e samples) PWM (analog)
X
14 LCD LPL 42 X 1080p 1920
LC420WU1-SL01-v0.0 PWM 8
15 PDP SDI 37 480p 852
NA
16 PDP FHP 37 1080i 1024
NA
NA
17 PDP FHP 42 1080i 1024
Tbd
X
18 PDP FHP 55 768p 1366
FPF55C17196UA-51-v04 NA 10
19 LCOS VENUS 720p 1280 NA
20 LCOS VENUS X 1080p 1920
NA
21 LCD LPL 26 768p 1366 LC260WX2 - SL01 - v1,0
PWM 8
S *
22 LCD LPL 32 X 768p 1366
LC320WX2-SL01 analog 8
X
23 PDP LG 42 480p 852
PDP42x2#56# Rev.00 NA 8
24 PDP SDI V4 42 480p 852
V4_S42SD-YD07-v0.0 NA 10 (8)
X
25 PDP SDI V5 42 768p 1024
V4-S42AX-YD01-Rev0.1 NA 10 (8)
XX
26 PDP FHP A2 42 1024i 1024
FPF42C128128UD-51 NA 8
27 PDP SDI HD V5” SDI V5 50 768p 1366
V4-S50HW-XD04-v0.2 NA 10(8)
XX
28 LCD Sharp 37 X 1080P 1920
LQ370D3LZ1x ASV2.2 analog 10(8)
X
p
PWM
768p 1366
(analog)
LW370D3LZ1xASV3.0
(1e sample)
31 LCD Sharp 37 X X 1080P 1920
LQ370D3LZ1x ASV3.0 PWM 10(8)
XX
32 LCD LPL 20 768p 1366
LC200WX1-SL01 tbd
S
33 LCD QDI 23 768p 1366
QD23HL tbd
S
34 ECO PTV 51 1080i 1366
NA n.a. (8)
S
35 ECO PTV 55 1080i 1366
NA n.a. (8)
S
36 ECO PTV 61 1080i 1366
NA
NA
NA
NA?
?
n.a. (8)
S
37 PDP FHP A3 42 1024I 1024
FPF42128135UA
38 DLP 50 720p 1280
10
S
39 DLP 60 720p 1280
10
S
40 LCD Sharp 2.3 32 768p 1366
ASV 2.3 PWM (analog) 8
X
41 LCD LPL 42 X 768p 1366
LC420WX2-SLA1 analog
XX
42 PDP SDI V4 63 768p 1366
NA
X
43 LCD Sharp 3.0 37 X 768p 1366
ASV 3.0 PWM
44 LCD Sharp 2.3 37 768p 1366
ASV 2.3 PWM (analog)
XX
45 LCD LPL 26 768p 1366 LC260WX2 - SLB2 - v0,0
PWM 8
X
46 LCD LPL 32 768 p 1366
LCD320W01-SL06 PWM 8
S
47 LCD LPL 42 768p 1366
SLB1 PWM 8
X
48 LCD QDI 26 768p 1366
QD26HDL02 PWM 8
S
49 LCD AUO 26 768p 1366
T260XW02 V4 PWM 8
X
50 LCD AUO 32 768p 1366
T315XW01 V9 PWM 8
S
51 LCD AUO 37 768p 1366
T370XW01 V1 PWM 8
S
52 LCD AUO 32 768p 1366
T315XW02V5 PWM 8
X
53 LCD LPL 37 768p 1366
LC370WX01-SL04 PWM 8
S
54 PDP LGE 42 768p 1024
LGE 42” XGA X3 NA 10
X
PWM 10(8)
X30 LCD Sharp 37 X X 1080p 1920
29 LCD AUO 32
T315XW01-V3-V0.1 8
X
analog 8
13 LCD Sharp 37 768p 1366
Xion1,05-v0.01 NA 8
720p 12809 LCOS XION
8
6 LCD Sharp 32 768p 1366
analog
NA 10 (8)
NA 8
2k6
1 PDP SDI v3 50 768p 1366 V3-S50HW-XD03-v0,0
Hor Output
Res
2k5
Displays
Div.Displays
Clarification Resolution Year
Display Type Brand
Size
(Inch)
Full HD
Clear
LCD
Ver Output
Res
