Philips 42PF9731D - Page 190

Spare Parts List
EN 190 BJ2.4U/BJ2.5U LA10.
6P80 4822 130 11397 BAS316
6P81 4822 130 11152 UDZ18B
6P82 4822 130 11397 BAS316
6P83 4822 130 11397 BAS316
6P84 4822 130 11397 BAS316
6P85 4822 130 11397 BAS316
6S01 5322 130 31938 BYV27-200
6S04 9340 548 69115 PDZ27B
6S05 4822 130 11522 UDZ15B
6S07 4822 130 11572 STPS8H100F
6S09 4822 130 11522 UDZ15B
6S10 9322 102 64685 UDZ2.7B
6S11 4822 130 11397 BAS316
6S12 9322 202 55685 BYG22D
6S13 4822 130 11397 BAS316
6S30 9322 203 12673 BYV27-600
6S31 4822 130 11522 UDZ15B
6S47 9322 208 44685 BZG05C6V8
6S49 3198 020 55680 BZX384-C5V6
ce
7D00 9322 213 18668 LM393PW
7D05 3198 010 42310 BC847BW
7D06 3198 010 44350 BC807-25W
7D07 3198 010 42310 BC847BW
7D08 3198 010 42320 BC857BW
7D09 9340 219 30115 BC817-25W
7D10 9322 224 40668 FET FDS4559_NL
7D12 3198 010 42320 BC857BW
7D30 3198 010 42310 BC847BW
7D31 3198 010 44350 BC807-25W
7D32 3198 010 42310 BC847BW
7D33 3198 010 42320 BC857BW
7D34 9340 219 30115 BC817-25W
7D35 9322 224 40668 FET FDS4559_NL
7D37 3198 010 42320 BC857BW
7D40 9322 185 74668 LM324P
7DF0 3198 010 42310 BC847BW
7DF1 3198 010 42310 BC847BW
7DF2 3198 010 42320 BC857BW
7DF3 3198 010 42310 BC847BW
7DF4 3198 010 42310 BC847BW
7DF5 3198 010 42310 BC847BW
7DF6 3198 010 42320 BC857BW
7DF7 9322 213 18668 LM393PW
7DF8 3198 010 42310 BC847BW
7DH1 3198 010 42310 BC847BW
7DK0 9322 224 40668 FET FDS4559_NL
7DK1 9322 213 18668 LM393PW
7DK2 3198 010 44350 BC807-25W
7DK3 3198 010 42320 BC857BW
7DK4 3198 010 42310 BC847BW
7DK5 3198 010 42320 BC857BW
7DK6 9340 219 30115 BC817-25W
7DK7 3198 010 42310 BC847BW
7DL0 9322 224 40668 FET FDS4559_NL
7DL1 3198 010 44350 BC807-25W
7DL2 3198 010 42320 BC857BW
7DL3 3198 010 42310 BC847BW
7DL4 3198 010 42310 BC847BW
7DL5 3198 010 42320 BC857BW
7DL6 9340 219 30115 BC817-25W
7P02 9322 194 26687 STP6NK60Z
7P03 9322 192 16685 TS2431AI
7P04 3198 010 42310 BC847BW
7P06 9340 219 30115 BC817-25W
7P07 3198 010 42320 BC857BW
7P09 3198 010 42310 BC847BW
7P10 3198 010 42310 BC847BW
7P11
h 9322 149 04682 TCET1102
7P12
h 9322 149 04682 TCET1102
7P14 9340 557 69127 PHX9NQ20T
7P15 3198 010 42310 BC847BW
7P16 9322 192 16685 TS2431AI
7P17 3198 010 42310 BC847BW
7P18 9340 436 50115 BSP030
7P19 3198 010 42310 BC847BW
7P20 9340 436 50115 BSP030
7P21 3198 010 42310 BC847BW
7P22 3198 010 42320 BC857BW
7P23 9340 436 50115 BSP030
7P24 3198 010 42320 BC857BW
7P26 9340 219 30115 BC817-25W
7P27 9352 743 34518 TEA1506AT/N1
7P38 3198 010 42310 BC847BW
7P80 3198 010 42310 BC847BW
7P81 9322 192 16685 TS2431AI
7P82 3198 010 42320 BC857BW
7S02 9322 194 26687 STP6NK60Z
7S03
h 9322 149 04682 TCET1102
7S04 9322 192 16685 TS2431AI
7S10 9352 700 18518 TEA1533AT/N1
7S11 9340 219 30115 BC817-25W
7S31 9340 436 50115 BSP030
7S40 3198 010 42310 BC847BW
Small Signal Board [B]
e Software (see Philips Service Website)
0802 Downloadable file
Various
1B01 2422 033 00018 Connector 19p f
1B02 2422 033 00018 Connector 19p f
1B30 2422 549 00146 Line filter 20V 3A
1B31 2422 549 00146 Line filter 20V 3A
1B32 2422 549 00146 Line filter 20V 3A
1B33 2422 549 00146 Line filter 20V 3A
1B34 2422 549 00146 Line filter 20V 3A
1B35 2422 549 00146 Line filter 20V 3A
1B36 2422 549 00146 Line filter 20V 3A
1B37 2422 549 00146 Line filter 20V 3A
1C33
h 2422 086 11092 Fuse 500mA 50V F SMD
1C52 2422 549 44377 Filter 45.75MHz
1C54 2422 549 00505 Filter 4.5MHz
1D42 4822 267 10637 Connector 5p
1E40 2422 025 17601 Connector 40p f
1E62 2422 025 17759 Connector 20p f
1G01 2422 540 00017 Reson. 60MHz CSTCW
1G02 2422 540 00012 Reson. 10MHz CSTCE
1G50 2422 025 18427 Connector 31p f
1H00 2422 543 01397 Xtal 27MHz 18pF
1H01 2422 025 17775 Socket USB 4p f
1LA0 2422 543 01443 Xtal 16MHz 20pF
1M03 2422 025 10771 Connector 10p m
1M15 2422 025 18749 Connector 3p m
1M46 2422 025 10655 Connector 11p m
1M52 2422 025 18744 Connector 9p m
1M59 2422 025 19265 Connector 5p m Bk
1M63 2422 025 09405 Connector 2p m
1M64 2422 025 18779 Connector 4p m
1N00 2422 543 01095 Res. 12MHz DSX840
1N62 2422 025 18779 Connector 4p m
1P01 2422 025 19501 Socket PCMCIA H 68P f
1T04 3112 297 14221 Tuner TD1336O/FGHP
1T41 2422 549 00137 Filter 44MHz
1T44 2422 549 00137 Filter 44MHz
1T55
h 2422 086 11092 Fuse 500mA 50V F SMD
1TG0 2422 543 01522 Xtal 25.140MHz 20pF
1U01
h 2422 086 00623 Fuse 3A T 125V
1U04
h 2422 086 00623 Fuse 3A T 125V
g
2A01 2238 586 59812 100nF 20% 50V 0603
2A20 4822 124 12095 100µF 20% 16V
2A21 4822 124 12095 100µF 20% 16V
2A22 2022 552 05679 1µF 10% 16V 0805
2A23 2020 552 96618 1nF 10% 50V 0402
2A24 2238 586 59812 100nF 20% 50V 0603
2A25 2238 586 59812 100nF 20% 50V 0603
2A29 2238 586 59812 100nF 20% 50V 0603
2A31 2238 586 59812 100nF 20% 50V 0603
2A32 4822 124 80151 47µF 16V
2A34 2238 869 15101 100pF 5% 50V 0402
2A35 2238 869 15101 100pF 5% 50V 0402
2A36 2238 869 15101 100pF 5% 50V 0402
2A37 2020 552 96628 10nF 10% 16V 0402
2A38 2238 869 15101 100pF 5% 50V 0402
2A39 2020 552 96618 1nF 10% 50V 0402
2A75 2238 869 15101 100pF 5% 50V 0402
2A76 2238 869 15101 100pF 5% 50V 0402
2A77 2238 869 15101 100pF 5% 50V 0402
2A79 2022 552 05679 1µF 10% 16V 0805
2A80 3198 035 02210 220pF 5% 50V 0402
2A81 2022 552 05679 1µF 10% 16V 0805
2A83 2022 552 05679 1µF 10% 16V 0805
2A84 2022 552 05679 1µF 10% 16V 0805
2A85 2238 586 59812 100nF 20% 50V 0603
2A86 2022 552 05679 1µF 10% 16V 0805
2A87 2022 552 05679 1µF 10% 16V 0805
2A88 2238 586 59812 100nF 20% 50V 0603
2A89 4822 126 14324 33pF 5% 50V 0402
2A90 4822 126 14324 33pF 5% 50V 0402
2A91 2022 552 05679 1µF 10% 16V 0805
2A93 2238 586 59812 100nF 20% 50V 0603
2A96 2238 586 59812 100nF 20% 50V 0603
2A98 4822 126 14324 33pF 5% 50V 0402
2A99 4822 126 14324 33pF 5% 50V 0402
2AA0 4822 124 12095 100µF 20% 16V
2AA1 4822 124 80151 47µF 16V
2AA2 4822 124 12095 100µF 20% 16V
2AA3 2238 586 59812 100nF 20% 50V 0603
2AA4 4822 124 12108 100µF 20% 4V
2AA5 4822 126 13879 220nF +80-20% 16V
2AA6 2022 552 05679 1µF 10% 16V 0805
2AB1 2020 552 96618 1nF 10% 50V 0402
2AB2 2020 552 96618 1nF 10% 50V 0402
2AB5 2020 552 96618 1nF 10% 50V 0402
2AB7 2238 586 59812 100nF 20% 50V 0603
2AB8 3198 035 03310 330pF 5% 50V 0402
2B00 2238 586 59812 100nF 20% 50V 0603
2B01 2238 586 59812 100nF 20% 50V 0603
2B02 2238 586 59812 100nF 20% 50V 0603
2B04 2238 586 59812 100nF 20% 50V 0603
2B05 2238 586 59812 100nF 20% 50V 0603
2B21 2020 552 96628 10nF 10% 16V 0402
2B22 2020 552 96628 10nF 10% 16V 0402
2B23 2020 552 96628 10nF 10% 16V 0402
2B24 2020 552 96628 10nF 10% 16V 0402
2B25 2020 552 96628 10nF 10% 16V 0402
2B26 2020 552 96628 10nF 10% 16V 0402
2B27 2020 552 96628 10nF 10% 16V 0402
2B28 2020 552 96628 10nF 10% 16V 0402
2B29 2020 552 96628 10nF 10% 16V 0402
2B30 2020 552 96628 10nF 10% 16V 0402
2B31 2020 552 96628 10nF 10% 16V 0402
2B32 2238 869 15109 10pF 5% 50V 0402
2B33 2238 869 15109 10pF 5% 50V 0402
2B34 2238 869 15109 10pF 5% 50V 0402
2B35 2238 869 15109 10pF 5% 50V 0402
2B36 2238 869 15109 10pF 5% 50V 0402
2B37 2238 869 15109 10pF 5% 50V 0402
2B38 2022 552 05679 1µF 10% 16V 0805
2B39 2020 004 00003 330µF 20% 6.3V
2B40 2238 586 59812 100nF 20% 50V 0603
2B41 2238 586 59812 100nF 20% 50V 0603
2B42 2238 586 59812 100nF 20% 50V 0603
2B43 4822 117 13605 Jumper 0402
2B44 2020 552 96628 10nF 10% 16V 0402
2B45 2020 552 96628 10nF 10% 16V 0402
2B46 2020 552 96628 10nF 10% 16V 0402
2B49 2238 586 59812 100nF 20% 50V 0603
2B51 2238 586 59812 100nF 20% 50V 0603
2B52 2238 586 59812 100nF 20% 50V 0603
2B53 2238 586 59812 100nF 20% 50V 0603
2B62 2238 586 59812 100nF 20% 50V 0603
2B64 2238 586 59812 100nF 20% 50V 0603
2B67 4822 124 81058 47µF 20% 4V
2B69 2238 586 59812 100nF 20% 50V 0603
2B77 2238 586 59812 100nF 20% 50V 0603
2B79 2238 586 59812 100nF 20% 50V 0603
2B80 2238 586 59812 100nF 20% 50V 0603
2B81 2238 586 59812 100nF 20% 50V 0603
2B89 5322 126 11583 10nF 10% 50V 0603
2B90 4822 124 81058 47µF 20% 4V
2B92 2238 586 59812 100nF 20% 50V 0603
2BA0 2020 552 96628 10nF 10% 16V 0402
2BA1 3198 035 14720 4.7nF 5% 25V 0402
2BA2 2020 552 96628 10nF 10% 16V 0402
2BA3 3198 035 14720 4.7nF 5% 25V 0402
2BA4 3198 034 01580 1.5pF 1% 50V 0402
2BA5 3198 034 01580 1.5pF 1% 50V 0402
2BA6 3198 034 01580 1.5pF 1% 50V 0402
2BA7 3198 034 01580 1.5pF 1% 50V 0402
2BA8 3198 034 01580 1.5pF 1% 50V 0402
2BA9 3198 034 01580 1.5pF 1% 50V 0402
2C01 2238 787 15641 22nF 5% 16V 0402
2C02 2238 787 15641 22nF 5% 16V 0402
2C04 2238 787 15641 22nF 5% 16V 0402
2C05 2238 787 15641 22nF 5% 16V 0402
2C06 2238 787 15641 22nF 5% 16V 0402
2C07 2238 787 15641 22nF 5% 16V 0402
2C08 2238 787 15641 22nF 5% 16V 0402
2C09 2238 787 15641 22nF 5% 16V 0402
2C11 2238 787 15641 22nF 5% 16V 0402
2C14 2238 787 15641 22nF 5% 16V 0402
2C22 2238 787 15641 22nF 5% 16V 0402
2C23 2238 787 15641 22nF 5% 16V 0402
2C27 2238 586 59812 100nF 20% 50V 0603
2C28 2238 586 59812 100nF 20% 50V 0603
2C31 2238 586 59812 100nF 20% 50V 0603
2C32 2020 004 90283 10µF 20% 10V 1206
2C33 2238 586 59812 100nF 20% 50V 0603
2C34 2022 552 05679 1µF 10% 16V 0805
2C35 2238 586 59812 100nF 20% 50V 0603
2C36 2022 552 05679 1µF 10% 16V 0805
2C37 2022 552 05679 1µF 10% 16V 0805
2C39 2238 586 59812 100nF 20% 50V 0603
2C40 2238 586 59812 100nF 20% 50V 0603
2C42 4822 126 14519 22pF 5% 50V 0402
2C43 4822 124 12108 100µF 20% 4V
2C44 2238 586 59812 100nF 20% 50V 0603
2C45 2020 004 90283 10µF 20% 10V 1206
2C46 2022 552 05679 1µF 10% 16V 0805
