Spare Parts List
EN 198 BJ2.4U/BJ2.5U LA10.
3910 4822 051 30392 3.9Ω 5% 0.063W 0603
3911 4822 051 30103 10kΩ 5% 0.062W
3912 4822 051 30103 10kΩ 5% 0.062W
3999 4822 051 30102 1kΩ 5% 0.062W
b
5001 2422 549 44197 Bead 220Ω at 100MHz
d
6900 4822 130 11416 PDZ6.8B
6901 4822 130 11416 PDZ6.8B
6902 4822 130 11416 PDZ6.8B
6903 4822 130 11416 PDZ6.8B
6904 4822 130 11416 PDZ6.8B
6905 4822 130 11416 PDZ6.8B
6906 4822 130 11416 PDZ6.8B
6907 4822 130 11416 PDZ6.8B
6908 4822 130 11416 PDZ6.8B
6909 4822 130 11416 PDZ6.8B
6910 4822 130 11416 PDZ6.8B
6911 4822 130 11416 PDZ6.8B
Control Panel [E]
Various
1701 4822 276 13775 Switch 1p 0.1A 12V
1702 4822 276 13775 Switch 1p 0.1A 12V
1703 4822 276 13775 Switch 1p 0.1A 12V
1704 4822 276 13775 Switch 1p 0.1A 12V
1705 4822 276 13775 Switch 1p 0.1A 12V
1706 4822 276 13775 Switch 1p 0.1A 12V
1M01 4822 267 10459 Connector 3p
f
3002 4822 051 30151 150Ω 5% 0.062W
3002 4822 051 30681 680Ω 5% 0.062W
3003 4822 051 30102 1kΩ 5% 0.062W
3003 4822 051 30391 390Ω 5% 0.062W
3004 4822 051 30102 1kΩ 5% 0.062W
3004 4822 051 30561 560Ω 5% 0.062W
3005 3198 021 31820 1.8kΩ 5% 0.062W 0603
3005 4822 051 30391 390Ω 5% 0.062W
3006 4822 051 30101 100Ω 5% 0.062W
3006 4822 117 12968 820Ω 5% 0.62W
3008 4822 051 30102 1kΩ 5% 0.062W
3009 4822 051 30101 100Ω 5% 0.062W
3999 4822 051 30103 10kΩ 5% 0.062W
3999 4822 117 12968 820Ω 5% 0.62W
9002 4822 051 30101 100Ω 5% 0.062W
Keyboard LED Panel [J]
Various
1040 9322 206 81667 TSOP34836YA1
1040 9322 223 97668 TSOP36236 IR
1M01 2422 025 18738 Connector 3p m
1M20 2422 025 18736 Connector 12p m
1M21 2422 025 18753 Connector 6p m
g
2014 2238 586 59812 100nF 20% 50V 0603
2040 4822 124 12095 100µF 20% 16V
2070 4822 124 12095 100µF 20% 16V
2070 4822 126 14583 470nF 10% 16V 0805
2071 4822 124 23002 10µF 16V
f
3040 4822 117 13597 330Ω 5% 0.01W 0402
3041 4822 117 13606 10kΩ 5% 0.01W 0402
3042 3198 031 06820 6.8kΩ 5% 0.01W 0402
3051 4822 051 30331 330Ω 5% 0.062W
3051 4822 117 13597 330Ω 5% 0.01W 0402
3053 4822 117 13606 10kΩ 5% 0.01W 0402
3055 4822 051 30103 10kΩ 5% 0.062W
3055 4822 117 13606 10kΩ 5% 0.01W 0402
3056 4822 051 30103 10kΩ 5% 0.062W
3058 4822 117 13606 10kΩ 5% 0.01W 0402
3059 4822 117 13606 10kΩ 5% 0.01W 0402
3061 4822 051 30331 330Ω 5% 0.062W
3061 4822 117 13597 330Ω 5% 0.01W 0402
3063 4822 117 13606 10kΩ 5% 0.01W 0402
3065 4822 117 13606 10kΩ 5% 0.01W 0402
3068 4822 117 13606 10kΩ 5% 0.01W 0402
3069 4822 117 13606 10kΩ 5% 0.01W 0402
3070 2322 705 70475 4.7MΩ 5% 0402
3071 2322 705 70475 4.7MΩ 5% 0402
3071 4822 117 13603 33kΩ 5% 0402
3072 4822 117 13548 1kΩ 5% 0402
3072 4822 117 13606 10kΩ 5% 0.01W 0402
3073 3198 031 03320 3.3kΩ 5% 0402
3074 4822 117 13606 10kΩ 5% 0.01W 0402
3075 3198 031 04720 4.7kΩ 5% 0402
3076 3198 031 03320 3.3kΩ 5% 0402
3077 3198 031 03320 3.3kΩ 5% 0402
3077 4822 117 13606 10kΩ 5% 0.01W 0402
3079 2322 705 70475 4.7MΩ 5% 0402
3999 4822 117 13606 10kΩ 5% 0.01W 0402
9011 4822 117 13605 Jumper 0402
9012 4822 117 13605 Jumper 0402
9015 4822 117 13605 Jumper 0402
9016 4822 117 13605 Jumper 0402
9017 4822 117 13605 Jumper 0402
9041 4822 117 13605 Jumper 0402
9042 4822 117 13605 Jumper 0402
9056 4822 117 13605 Jumper 0402
9071 4822 117 13605 Jumper 0402
9072 4822 117 13605 Jumper 0402
9120 4822 117 13605 Jumper 0402
9121 4822 117 13605 Jumper 0402
d
6051 4822 130 83915 TLMV3100
6051 9322 218 97685 SML-310VTK
6060 9322 134 46685 SML-310MT
6070 9322 140 63685 TEMD5000
ce
7051 3198 010 42310 BC847BW
7052 4822 130 60373 BC856B
7061 3198 010 42310 BC847BW
7062 4822 130 60373 BC856B
7070 9322 192 63668 LM358P
7070 9322 218 83685 TEMT6000
7071 3198 010 42310 BC847BW
Standby & Audio Panel [SA]
Various
1316 2422 025 10772 Connector 12p m
1319 2422 025 10773 Connector 14p m
1735 2422 025 16382 Connector 3p m
1735 4822 267 10918 Connector 3p
1736 2422 025 10768 Connector 3p m
1736 4822 267 10735 Connector 3p
1739 2422 025 10769 Connector 9p m
1M02 2422 025 11244 Connector 7p m
1M03 2422 025 10771 Connector 10p m
1M10 2422 025 08149 Connector 6p m
1M10 2422 025 09406 Connector 4p m
1M46 2422 025 10655 Connector 11p m
1M52 2422 025 10769 Connector 9p m
1M63 2422 025 09405 Connector 2p m
1P02 2422 025 16374 Connector 2p m
1P03 2422 086 00717 Fuse 1.6A T 250V
1P06 2422 086 00678 Fuse 5A T 250V
1P07 2422 086 00678 Fuse 5A T 250V
1P10 4822 267 10557 Connector 10p
1P22 4822 265 20723 Connector 2p
1P30 2422 086 00663 Fuse 1A T 250V
g
2131 2238 586 15641 22nF 10% 50V 0603
2132 4822 124 40207 100µF 20% 25V
2160 4822 124 21913 1µF 20% 63V
2515 4822 126 14238 2.2nF 50V 0603
2538 5322 126 11583 10nF 10% 50V 0603
2702 5322 126 11578 1nF 10% 50V 0603
2704 5322 126 11578 1nF 10% 50V 0603
2705 2020 552 96684 470nF 10% 25V 0805
2706 2222 580 15649 100nF 10% 50V 0805
2707 4822 126 14585 100nF 10% 0805 50V
2708 2020 552 96326 220nF 10% 16V
2709 4822 126 13881 470pF 5% 50V
2710 4822 126 13881 470pF 5% 50V
2711 5322 126 11578 1nF 10% 50V 0603
2712 2020 552 96683 220nF 10% 50V
2713 2020 552 96684 470nF 10% 25V 0805
2714 3198 017 33330 33nF 20% 16V 0603
2715 5322 126 11578 1nF 10% 50V 0603
2716 4822 126 14241 330pF 0603 50V
2717 5322 121 42498 680nF 5% 63V
2718 4822 122 33761 22pF 5% 50V
2719 5322 126 11578 1nF 10% 50V 0603
2720 2020 552 96326 220nF 10% 16V
2721 4822 126 13881 470pF 5% 50V
2722 4822 126 13881 470pF 5% 50V
2725 2020 552 94427 100pF 5% 50V
2726 3198 017 33330 33nF 20% 16V 0603
2727 5322 126 11578 1nF 10% 50V 0603
2728 4822 126 14241 330pF 0603 50V
2729 5322 121 42498 680nF 5% 63V
2764 4822 126 14491 2.2µF 10V 0805
2766 4822 126 14491 2.2µF 10V 0805
2768 4822 124 40255 100µF 20% 63V
2769 4822 124 40255 100µF 20% 63V
2777 2020 552 96683 220nF 10% 50V
2778 4822 124 40769 4.7µF 20% 100V
2779 2020 552 96683 220nF 10% 50V
2780 2020 552 96683 220nF 10% 50V
2781 2020 552 96683 220nF 10% 50V
2783 4822 124 41751 47µF 20% 50V
2786 2238 586 15641 22nF 10% 50V 0603
2788 4822 124 40255 100µF 20% 63V
2789 2020 552 96683 220nF 10% 50V
2790 4822 124 40255 100µF 20% 63V
2D00 3198 017 34730 47nF 16V 0603
2D01 5322 126 11578 1nF 10% 50V 0603
2D02 5322 126 11583 10nF 10% 50V 0603
2D03 2238 916 11552 1.5nF 5% 25V 0603
2D04 2238 916 11552 1.5nF 5% 25V 0603
2D05 2022 552 05679 1µF 10% 16V 0805
2D06 4822 124 80061 1000µF 20% 25V
2D07 2222 580 15649 100nF 10% 50V 0805
2D08 4822 126 14247 1.5nF 50V 0603
2D09 4822 126 14247 1.5nF 50V 0603
2D10 2020 552 96828 470nF 20% 25V
2D12 2222 580 15649 100nF 10% 50V 0805
2D13 4822 124 80061 1000µF 20% 25V
2D14 2222 580 15649 100nF 10% 50V 0805
2D16 4822 122 33741 10pF 10% 50V
2D17 4822 122 33741 10pF 10% 50V
2D18 4822 122 33741 10pF 10% 50V
2D19 4822 122 33741 10pF 10% 50V
2D20 2222 580 15649 100nF 10% 50V 0805
2D21 2222 580 15649 100nF 10% 50V 0805
2D25 3198 017 34730 47nF 16V 0603
2D26 5322 126 11578 1nF 10% 50V 0603
2D27 5322 126 11583 10nF 10% 50V 0603
2D28 2238 916 11552 1.5nF 5% 25V 0603
2D29 2238 916 11552 1.5nF 5% 25V 0603
2D30 2022 552 05679 1µF 10% 16V 0805
2D31 4822 124 80061 1000µF 20% 25V
2D32 2222 580 15649 100nF 10% 50V 0805
2D33 4822 126 14247 1.5nF 50V 0603
2D34 4822 126 14247 1.5nF 50V 0603
2D35 2020 552 96828 470nF 20% 25V
2D37 2222 580 15649 100nF 10% 50V 0805
2D38 4822 124 80061 1000µF 20% 25V
2D39 2222 580 15649 100nF 10% 50V 0805
2D40 2222 580 15649 100nF 10% 50V 0805
2D44 2238 586 59812 100nF 20% 50V 0603
2D45 2238 586 59812 100nF 20% 50V 0603
2DD1 2020 552 94427 100pF 5% 50V
2DD2 5322 126 11578 1nF 10% 50V 0603
2DD4 4822 126 14247 1.5nF 50V 0603
2DD5 2020 552 94427 100pF 5% 50V
2DD6 5322 126 11578 1nF 10% 50V 0603
2DD7 5322 126 11578 1nF 10% 50V 0603
2DD8 5322 126 11583 10nF 10% 50V 0603
2DF0 2022 552 05679 1µF 10% 16V 0805
2DF2 2222 580 15649 100nF 10% 50V 0805
2DF3 2222 580 15649 100nF 10% 50V 0805
2DF5 2238 586 59812 100nF 20% 50V 0603
2DF9 5322 126 11583 10nF 10% 50V 0603
2F00 2020 024 90753 100µF 450V 20%
2P01 2022 552 05679 1µF 10% 16V 0805
2P03 2022 552 05679 1µF 10% 16V 0805
2P04 2022 552 05679 1µF 10% 16V 0805
2P05 4822 124 81151 22µF 50V
2P06 2022 554 04154 220pF 10% 250V
2P11 2022 552 05679 1µF 10% 16V 0805
2P12 2238 586 59812 100nF 20% 50V 0603
2P13 2238 586 59812 100nF 20% 50V 0603
2P14 4822 121 70162 10nF 5% 400V
2P21 2238 586 59812 100nF 20% 50V 0603
2P22 2020 552 96683 220nF 10% 50V
2P23 5322 126 11578 1nF 10% 50V 0603
2P24 2022 552 05679 1µF 10% 16V 0805
2P25 2252 053 63221 220pF 10% 200V 0805
2P26 2020 552 96683 220nF 10% 50V
2P27 3198 038 41020 1000µF 20% 35V
