Philips 42PF9731D - Page 200

Spare Parts List
EN 200 BJ2.4U/BJ2.5U LA10.
3S14 4822 051 30222 2.2kΩ 5% 0.062W
3S15 4822 051 30103 10kΩ 5% 0.062W
3S16 4822 051 30101 100Ω 5% 0.062W
3S17 4822 051 20479 47Ω 5% 0.1W
3S18 4822 051 30102 1kΩ 5% 0.062W
3S20 4822 117 12864 82kΩ 5% 0.6W
3S21 4822 051 30102 1kΩ 5% 0.062W
3S22 4822 051 20479 47Ω 5% 0.1W
3S23 5322 117 13053 6.8kΩ 1% 0.063W 0603
3S24 5322 117 13053 6.8kΩ 1% 0.063W 0603
3S28 3198 021 32290 22Ω 5% 0603
3S29 4822 051 30471 47Ω 5% 0.062W
3S30 4822 051 30123 12kΩ 5% 0.1W
3S31 4822 051 30124 120kΩ 5% 0.062W
3S32 4822 051 30334 330kΩ 5% 0.062W
3S33 4822 051 30333 33kΩ 5% 0.062W
3S34 4822 051 30333 33kΩ 5% 0.062W
3S35 4822 051 30472 4.7Ω 5% 0.062W
3S36 4822 051 30472 4.7Ω 5% 0.062W
3S37 4822 051 30102 1kΩ 5% 0.062W
3S39 3198 021 34780 4.7Ω 5% 0603
3S41 4822 051 30471 47Ω 5% 0.062W
3S50 3198 021 32290 22Ω 5% 0603
3S51 2322 193 14104 100kΩ 5%
3S59 4822 117 12891 220kΩ 1%
3S76 4822 051 30103 10kΩ 5% 0.062W
9004 3198 036 90010 Wire 0.58mm
9005 3198 036 90010 Wire 0.58mm
9006 3198 036 90010 Wire 0.58mm
9007 3198 036 90010 Wire 0.58mm
9010 3198 036 90010 Wire 0.58mm
9011 3198 036 90010 Wire 0.58mm
9014 4822 051 30109 10Ω 5% 0.062W
9015 4822 051 30008 Jumper 0603
9016 3198 036 90010 Wire 0.58mm
9024 4822 051 30008 Jumper 0603
9110 4822 051 30008 Jumper 0603
9120 4822 051 30008 Jumper 0603
9P04 4822 051 20008 Jumper 0805
9P58 4822 051 20008 Jumper 0805
9P80 4822 051 20008 Jumper 0805
9P81 4822 051 20008 Jumper 0805
b
5500h 2422 531 00076 BS25412-01 B
5701 2422 536 00951 68µH 20% LHL10
5702 2422 536 00951 68µH 20% LHL10
5703 4822 157 11716 Bead 30Ω at 100MHz
5705 4822 157 11716 Bead 30Ω at 100MHz
5707 4822 157 11411 Bead 80Ω at 100MHz
5708 4822 157 11411 Bead 80Ω at 100MHz
5711 4822 157 11411 Bead 80Ω at 100MHz
5712 4822 157 11411 Bead 80Ω at 100MHz
5730 2422 549 00112 Line filt. 50V 3A
5731 2422 549 00112 Line filt. 50V 3A
5D00 2422 536 00776 33µH 10%
5D01 4822 157 11411 Bead 80Ω at 100MHz
5D02 4822 157 11411 Bead 80Ω at 100MHz
5D05 4822 157 11411 Bead 80Ω at 100MHz
5D06 4822 157 11411 Bead 80Ω at 100MHz
5D25 2422 536 00776 33µH 10%
5D26 4822 157 11411 Bead 80Ω at 100MHz
5D27 4822 157 11411 Bead 80Ω at 100MHz
5F00
h 4822 157 11523 Line filter 5mH/2A
5P00 2422 531 00134 BS25504-02B
5P01 2422 531 00134 BS25504-02B
5P03 4822 157 50961 22µH
5P04 4822 157 11411 Bead 80Ω at 100MHz
5P05 4822 526 10704 Bead 50 Ω at 100MHz
5P06 4822 157 11411 Bead 80Ω at 100MHz
5P07 4822 157 11411 Bead 80Ω at 100MHz
5P08 4822 526 10704 Bead 50 Ω at 100MHz
5P09
h 4822 157 11832 400UH 3A
5P10 2422 549 00169 Bead 45Ω at 100MHz
5P11 2422 549 00169 Bead 45Ω at 100MHz
5P12 2422 549 00169 Bead 45Ω at 100MHz
5P13 2422 549 00169 Bead 45Ω at 100MHz
5P16 4822 157 11411 Bead 80Ω at 100MHz
5P18 2422 535 94636 3.3µF 20%
5P19 2422 535 94636 3.3µF 20%
5P20 2422 535 94636 3.3µF 20%
5P21 2422 549 44197 Bead 220Ω at 100MHz
5P22 2422 549 44197 Bead 220Ω at 100MHz
5P23 2422 549 44197 Bead 220Ω at 100MHz
5P24 2422 549 44197 Bead 220Ω at 100MHz
5P25 4822 157 11716 Bead 30Ω at 100MHz
5P26 4822 157 11716 Bead 30Ω at 100MHz
5P27 4822 157 11716 Bead 30Ω at 100MHz
5P28 4822 157 11716 Bead 30Ω at 100MHz
5S00 3104 308 21181 BS25320-00
5S01 4822 157 11828 22µH 20% 0805
5S03 4822 526 10704 Bead 50 Ω at 100MHz
5S05 4822 157 11411 Bead 80Ω at 100MHz
5S08 4822 526 10704 Bead 50 Ω at 100MHz
5S09 4822 157 11411 Bead 80Ω at 100MHz
5S10 2422 549 43769 Bead 30Ω at 100MHz
5S11 4822 157 11411 Bead 80Ω at 100MHz
5S12 4822 526 10704 Bead 50 Ω at 100MHz
5S14 2422 549 44197 Bead 220Ω at 100MHz
5S15 2422 549 44197 Bead 220Ω at 100MHz
5S16 4822 157 11716 Bead 30Ω at 100MHz
d
6107 4822 130 11572 STPS8H100F
6130 9322 129 41685 BZM55-C12
6132 4822 130 11416 PDZ6.8B
6134 4822 130 11397 BAS316
6511 9322 129 41685 BZM55-C12
6701 4822 130 11397 BAS316
6702 4822 130 11551 UDZS10B
6703 4822 130 11551 UDZS10B
6DF0 4822 130 11397 BAS316
6DF1 4822 130 11152 UDZ18B
6DF2 4822 130 11397 BAS316
6P01 9322 203 12673 BYV27-600
6P02 9322 203 12673 BYV27-600
6P03 9322 208 83685 BZG05C27
6P04 9322 208 83685 BZG05C27
6P05
h 9322 227 41687 Bridge GBL06L-7000E3
6P06 9322 099 61685 BYG10J
6P07 9322 099 61685 BYG10J
6P09 4822 130 11522 UDZ15B
6P10 9322 202 75687 BYW29FP-200
6P11 9322 202 75687 BYW29FP-200
6P12 9322 202 75687 BYW29FP-200
6P13 9322 202 75687 BYW29FP-200
6P14 4822 130 11397 BAS316
6P15 4822 130 11397 BAS316
6P22 4822 130 11522 UDZ15B
6P23 4822 130 11522 UDZ15B
6P27 9322 202 55685 BYG22D
6P31 4822 130 11522 UDZ15B
6P47 9322 208 44685 BZG05C6V8
6P50 4822 130 11522 UDZ15B
6P51 4822 130 11416 PDZ6.8B
6P52 4822 130 11522 UDZ15B
6P53 4822 130 11397 BAS316
6P80 4822 130 11397 BAS316
6P81 4822 130 11152 UDZ18B
6P82 4822 130 11397 BAS316
6P83 4822 130 11397 BAS316
6P84 4822 130 11397 BAS316
6P85 4822 130 11397 BAS316
6S01 5322 130 31938 BYV27-200
6S04 9340 548 69115 PDZ27B
6S05 4822 130 11522 UDZ15B
6S07 4822 130 11572 STPS8H100F
6S09 4822 130 11522 UDZ15B
6S10 9322 102 64685 UDZ2.7B
6S11 4822 130 11397 BAS316
6S12 9322 202 55685 BYG22D
6S13 4822 130 11397 BAS316
6S30 9322 203 12673 BYV27-600
6S31 4822 130 11522 UDZ15B
6S47 9322 208 44685 BZG05C6V8
6S49 3198 020 55680 BZX384-C5V6
ce
7131 9340 557 69127 PHX9NQ20T
7511 9337 331 10215 BST82
7512 9340 422 80115 PMSTA42
7700 9322 163 86682 TDA7490L
7701 3198 010 42310 BC847BW
7703 3198 010 42310 BC847BW
7704 3198 010 42310 BC847BW
7705 3198 010 42310 BC847BW
7706 3198 010 42320 BC857BW
7707 3198 010 42310 BC847BW
7708 3198 010 42310 BC847BW
7709 3198 010 42310 BC847BW
7710 3198 010 42310 BC847BW
7711 3198 010 42310 BC847BW
7D00 9322 213 18668 LM393PW
7D05 3198 010 42310 BC847BW
7D06 3198 010 44350 BC807-25W
7D07 3198 010 42310 BC847BW
7D08 3198 010 42320 BC857BW
7D09 9340 219 30115 BC817-25W
7D10 9322 224 40668 FET FDS4559_NL
7D12 3198 010 42320 BC857BW
7D30 3198 010 42310 BC847BW
7D31 3198 010 44350 BC807-25W
7D32 3198 010 42310 BC847BW
7D33 3198 010 42320 BC857BW
7D34 9340 219 30115 BC817-25W
7D35 9322 224 40668 FET FDS4559_NL
7D37 3198 010 42320 BC857BW
7DF0 3198 010 42310 BC847BW
7DF1 3198 010 42310 BC847BW
7DF2 3198 010 42320 BC857BW
7DF3 3198 010 42310 BC847BW
7DF4 3198 010 42310 BC847BW
7DF5 3198 010 42310 BC847BW
7DF6 3198 010 42320 BC857BW
7DF7 9322 213 18668 LM393PW
7DF8 3198 010 42310 BC847BW
7DH1 3198 010 42310 BC847BW
7P02 9322 194 26687 STP6NK60Z
7P03 9322 192 16685 TS2431AI
7P04 3198 010 42310 BC847BW
7P06 9340 219 30115 BC817-25W
7P07 3198 010 42320 BC857BW
7P09 3198 010 42310 BC847BW
7P10 3198 010 42310 BC847BW
7P11
h 9322 149 04682 TCET1102
7P12
h 9322 149 04682 TCET1102
7P14 9340 557 69127 PHX9NQ20T
7P15 3198 010 42310 BC847BW
7P16 9322 192 16685 TS2431AI
7P17 3198 010 42310 BC847BW
7P18 9340 436 50115 BSP030
7P19 3198 010 42310 BC847BW
7P20 9340 436 50115 BSP030
7P21 3198 010 42310 BC847BW
7P22 3198 010 42320 BC857BW
7P23 9340 436 50115 BSP030
7P24 3198 010 42320 BC857BW
7P26 9340 219 30115 BC817-25W
7P27 9352 743 34518 TEA1506AT/N1
7P38 3198 010 42310 BC847BW
7P80 3198 010 42310 BC847BW
7P81 9322 192 16685 TS2431AI
7P82 3198 010 42320 BC857BW
7S02 9322 194 26687 STP6NK60Z
7S03
h 9322 149 04682 TCET1102
7S04 9322 192 16685 TS2431AI
7S10 9352 700 18518 TEA1533AT/N1
7S11 9340 219 30115 BC817-25W
7S31 9340 436 50115 BSP030
7S40 3198 010 42310 BC847BW
