Philips 55PFL5907 - Control Panel; Terminals

English
11
Control panel
a (POWER/STANDBY)
 Press
toTurntheunitOnandgointoStandbymode.
 TocompletelyTurnOfftheunit,youmustunplugtheACpower
cord.
b CH +/−
 Presstoselectchannelsortomoveup(+)/down(−)when
selectingmenuitems.
c SOURCE
 Toggletoselecttheconnecteddevices.
Presstodecidethecommandofsettingwhenselectingmenu
items.
d VOLUME − / +
 Presstoadjustvolumedown(−)/up(+)ortomoveleft(−)/right
(+)whenselectingmenuitems.
e Ambient light sensor
 AltersthebrightnessoftheTVscreenautomaticallybydetecting
yourroomlightinglevel.Donotblockthelightsensorallowingit
toworkproperly.
f Power On indicator
 LightsupwhitewhentheunitisTurnedOnandasheswhilethe
unitisTurningOn.
g Infrared sensor
 ReceivesIRsignalsfromremotecontrol.
a
b
c
d
g ef
Terminals
ih l mj k n o
p
q
r
s
h Digital Audio Optical Output jack
 DigitalAudioOpticalOutputtohometheatersandotherDigital
Audiosystems.
i Digital Audio Output jack
 DigitalAudio(S/PDIF)OutputtohometheatersandotherDigital
Audiosystems.
j Ethernet port
 ForInternetconnectionusinganEthernetcablewithanRJ-45
connector.
k Component Audio Input jacks
 ComponentAnalogAudio(L/R)jackssignal.
l Component Video Input jacks
 
m PC Audio Input jack
 PCAnalogAudiojacksignalwithStereomini3.5mmplugAudio
cableonPC.
n VGA cable connection for PC

o 75 ohm Cable / Antenna connection
 SignalInputfromanantenna,cableorsatellite.
p USB terminal
 DataInputfromUSBMemoryStickonly.
 Donotconnectanydevicetothisterminalsuchas;Digital
camera,keyboard,mouse,etc.
q Composite (VIDEO) Video and Audio Input jacks for VIDEO
 CompositeVideo/AnalogAudio(L/R)jackssignal.
r HDMI Input jacks
 DigitalAudioandvideoInputfromhighdenitionDigitaldevices
suchasBlu-raydiscplayers,cableboxesandsatelliteset-top
boxes.
 ForHDMI1only
 InadditiontonormalHDMIandHDMI-DVIfunctionality,it
outputsTVAudiotoanHDMI-ARC-compliantdevice,suchasa
hometheatersystem.
s Headphone Audio Output jack
 Headphone3.5mmstereojackforpersonallistening.

