English
46
HDMI-ARC connection
HDMI-ARCallowsyoutouseEasyLinktooutputTVAudiodirectlyto
aconnectedAudiodevice,withouttheneedforanadditionalDigital
Audiocable.
OUT
HDMI-ARC
Digital home theater
amplier
HDMI cable
HDMI 1 IN only
Note
• TheHDMI1connectorisHDMIAudioReturnChannel(ARC)compliant.Useitto
outputDigitalAudiotoanHDMIhometheatersystem.
• BesurethatthedeviceisHDMICECandARCcompliantandthattheTVisconnected
tothedeviceusinganHDMIcableattachedtoHDMI-ARCconnectors.
Component Analog Video Connection
ComponentAnalogVideoconnectionoffersbetterpicturequalityfor
videodevicesconnectedtotheunit.
Ifyouconnecttotheunit’sComponentVideo(Y/Pb/Pr)Inputjacks,
connectAnalogAudiocablestotheAnalogAudio(L/R)Inputjacks.
OUTOUT
ININ
IN
IN
OUT
OUT
Component
(Y/Pb/Pr) Video cables
Audio (L/R) cables
set-top box
or
Blu-ray disc / DVD
recorder
Component dongle
Audio dongle
Note
• Theunitaccepts480i/480p/720pand1080i/pofvideosignalsforthisconnection.
Composite Analog Video Connection
CompositeAnalogVideoconnectionoffersstandardpicturequalityfor
videodevicesconnectedtotheunit.
Ifyouconnecttotheunit’sCompositeVideo(Y/VIDEO)Inputjack,
connectAudiocablestotheAudio(L/R)Inputjacks.WhentheAudiois
monaural,thenonlyconnecttotheAudioLInputjack.
OUT
ININ
DVD player
Audio (L/R) + Video cables
Composite dongle
Note
• Withthisunit,YellowcablemustbeconnectedtoY(Green)ofComponentVideoInput
jacks.
• WheneveryouconnecttotheCompositeVideoInputjack(Y/VIDEO),youmust
disconnecttheComponentVideoInputjacks(PbandPr).Ifyouleavethosejacks
connected,itmaycauseofunstablepicture.
• Onlytheleftloudspeakerreproducessoundformonoequipment.Useamonoto
stereoadapter(notsupplied)forsoundreproductionviaallinternalloudspeakers.
Connecting the TV to the Internet using an Ethernet cable
LAN
Network provisioning
equipment
Ethernet cable
Internet
Note
• PleasepurchaseshieldedEthernetcablesatyourlocalstoreandusethemwhenyou
connecttonetworkequipment.
• AfterconnectinganEthernetcable,setupnecessarynetworksettings.Network

➠
p. 40
• DonotinsertanycableotherthananEthernetcabletotheEthernetporttoavoid
damagingtheunit.
• Ifyourtelecommunicationsequipment(modem,etc.)doesnothavebroadbandrouter
functions,connectabroadbandrouter.
• Ifyourtelecommunicationsequipment(modem,etc.)hasbroadbandrouterfunctions
butthereisnovacantport,useahub.
• Forabroadbandrouter,usearouterwhichsupports10BASE-T/100BASE-TX.
• DonotconnectyourPCdirectlytotheEthernetportofthisunit.
 Continued on next page.
