Circuit Descriptions, Abbreviation List, and IC Data Sheets
EN 221JL2.1E AA 9.
Addressing the two boards
Figure 9-36 Ambilight board addressing
The Left and Right Ambi Light boards are the same on
hardware level, but the boards are able to work on different I
2
C
addresses: 6Ah for the left board and 6Ch for the right board.
The pre-programmed address depends on the value of the
RXD pin (H or L).
The first AL board is connected to the SSB by a four -wire
cable: I
2
C, ground, and one extra wire. The extra wire of this
cable is connected to ground on the SSB, in this way the first
board will be selected.
From the first board to the second board a three-wire cable is
used: I
2
C and ground. The extra connection doesn’t exist on
the second board, so the board will be identified as “AL 2”.
Pin 4 of connector 1M49 is connected to RXD line of the
microprocessor. This connection is connected to ground on the
SSB. The AL board, is programmed in such a way that it can
change his address, depending of the value at the RXD input
pin at start-up.
9.16 Abbreviation List
0/6/12 SCART switch control signal on A/V
board. 0 = loop through (AUX to TV), 6
= play 16:9 format, 12 = play 4:3
format
2DNR Spatial (2D) Noise Reduction
3DNR Temporal (3D) Noise Reduction
AARA Automatic Aspect Ratio Adaptation:
algorithm that adapts aspect ratio to
remove horizontal black bars; keeps
the original aspect ratio
ACI Automatic Channel Installation:
algorithm that installs TV channels
directly from a cable network by
means of a predefined TXT page
ADC Analogue to Digital Converter
AFC Automatic Frequency Control: control
signal used to tune to the correct
frequency
AGC Automatic Gain Control: algorithm that
controls the video input of the feature
box
AM Amplitude Modulation
ANR Automatic Noise Reduction: one of the
algorithms of Auto TV
AP Asia Pacific
AR Aspect Ratio: 4 by 3 or 16 by 9
ASF Auto Screen Fit: algorithm that adapts
aspect ratio to remove horizontal black
bars without discarding video
information
ATSC Advanced Television Systems
Committee, the digital TV standard in
the USA
ATV See Auto TV
Auto TV A hardware and software control
system that measures picture content,
and adapts image parameters in a
dynamic way
AV External Audio Video
AVIP Audio Video Input Processor
B/G Monochrome TV system. Sound
carrier distance is 5.5 MHz
BTSC Broadcast Television Standard
Committee. Multiplex FM stereo sound
system, originating from the USA and
used e.g. in LATAM and AP-NTSC
countries
B-TXT Blue TeleteXT
C Centre channel (audio)
CEC Consumer Electronics Control bus:
remote control bus on HDMI
connections
CL Constant Level: audio output to
connect with an external amplifier
COLUMBUS COlour LUMinance Baseband
Universal Sub-system
ComPair Computer aided rePair
CP Connected Planet / Copy Protection
CSM Customer Service Mode
CTI Colour Transient Improvement:
manipulates steepness of chroma
transients
CVBS Composite Video Blanking and
Synchronization
DAC Digital to Analogue Converter
DBE Dynamic Bass Enhancement: extra
low frequency amplification
DDC See "E-DDC"
D/K Monochrome TV system. Sound
carrier distance is 6.5 MHz
DFU Directions For Use: owner's manual
DMR Digital Media Reader: card reader
AL
AmbiLight
AL
AmbiLight
Supply
Standby Supply
Connections
I2C to second AL panel
3P
I2C & AL Board address
4P
PS +12V
PS +12V
SSB
I2C
I2C
F_15710_172.eps
230905
