8-4 8-4
ELECTRICAL PARTS LIST - FRONT CONTROL BOARD
MISCELLANEOUS
1300 2422 025 14541 Flex Socket 11pin Hort.
1301 4822 276 13775 Tact Switch
1302 4822 276 13775 Tact Switch
1303 4822 276 13775 Tact Switch
1304 4822 276 13775 Tact Switch
1305 4822 276 13775 Tact Switch
1306 4822 276 13775 Tact Switch
1307 4822 276 13775 Tact Switch
1308 4822 276 13775 Tact Switch
1309 4822 276 13775 Tact Switch
1310 4822 276 13775 Tact Switch
1311 4822 276 13775 Tact Switch
1312 4822 276 13775 Tact Switch
1314 4822 276 13775 Tact Switch
1315 4822 276 13775 Tact Switch
1400 4822 267 10953 Flex Socket 7pin Vert.
1402 4822 276 13775 Tact Switch
1405 4822 276 13775 Tact Switch
1501 4822 276 13775 Tact Switch
1502 4822 276 13775 Tact Switch
1503 4822 276 13775 Tact Switch
1701 2422 129 16501 Rotary Encoder 12P
1800 4822 265 11183 Flex Socket 4pin Hort.
1801 4822 265 11529 Headphone Socket
CAPACITORS
2300 4822 122 31765 100pF 2% 63V
2401 2020 552 96305 4,7µF +80/-20% 10V
2402 2020 552 96305 4,7µF +80/-20% 10V
2403 2020 552 96305 4,7µF +80/-20% 10V
2500 4822 122 31765 100pF 2% 63V
2700 5322 126 11583 10nF 10% 50V
2701 5322 126 11583 10nF 10% 50V
2800 4822 126 14494 22nF 10% 25V
2801 4822 126 14494 22nF 10% 25V
2802 4822 126 14494 22nF 10% 25V
RESISTORS
3300 4822 051 30272 2k7 5% 0,062W
3301 4822 051 30151 150R 5% 0,062W
3302 4822 051 30221 220R 5% 0,062W
3303 4822 051 30271 270R 5% 0,062W
3304 4822 051 30391 390R 5% 0,062W
3305 4822 051 30561 560R 5% 0,062W
3306 4822 117 12968 820R 5% 0,62W
3307 4822 117 11817 1k2 1% 1/16W
3308 4822 117 12903 1k8 1% 0.063W
3309 4822 051 30272 2k7 5% 0,062W
3310 4822 051 30472 4k7 5% 0,062W
3311 4822 051 30103 10k 5% 0,062W
3312 4822 051 30272 2k7 5% 0,062W
3313 4822 051 30151 150R 5% 0,062W
3314 4822 051 30221 220R 5% 0,062W
3315 4822 051 30271 270R 5% 0,062W
3316 4822 051 30221 220R 5% 0,062W
3317 4822 051 30221 220R 5% 0,062W
3318 4822 051 30221 220R 5% 0,062W
3319 4822 051 30221 220R 5% 0,062W
3400 4822 051 30391 390R 5% 0,062W
3401 4822 051 30561 560R 5% 0,062W
3402 4822 117 12925 47k 1% 0.063W
3403 4822 117 12968 820R 5% 0,62W
3404 4822 051 30103 10k 5% 0,062W
3405 4822 051 30101 100R 5% 0,062W
3500 4822 117 12968 820R 5% 0,62W
3501 4822 117 11817 1k2 1% 1/16W
3601 4822 117 12139 22R 5% 0,062W
3602 4822 117 12139 22R 5% 0,062W
3700 4822 051 30103 10k 5% 0,062W
3701 4822 051 30103 10k 5% 0,062W
4302 4822 051 30008 0R Jumper 0603
4401 4822 051 30008 0R Jumper 0603
4402 4822 051 30008 0R Jumper 0603
4403 4822 051 30008 0R Jumper 0603
4700 4822 051 30008 0R Jumper 0603
4703 4822 051 30008 0R Jumper 0603
4704 4822 051 30008 0R Jumper 0603
4800 4822 051 30008 0R Jumper 0603
4802 4822 051 30008 0R Jumper 0603
COILS & FILTERS
5800 4822 157 10586 Coil 2,2µH 10% 0805
5801 4822 157 10586 Coil 2,2µH 10% 0805
5802 4822 157 10586 Coil 2,2µH 10% 0805
DIODES
6300 4822 130 11589 LTL-1CHGE
6301 4822 130 11589 LTL-1CHGE
6302 4822 130 11589 LTL-1CHGE
6303 4822 130 11589 LTL-1CHGE
6400 9322 160 65676 LTL-4221NLC-VA
6601 9322 147 33676 LNX9A8BYB0PH
6602 9322 147 33676 LNX9A8BYB0PH
TRANSISTORS & INTEGRATED CIRCUITS
7400 9322 155 22667 IR Receiver TSOP2236ZC1
7402 4822 130 60373 BC857B
Note: Only the parts mentioned in this list are normal
service spare parts.
