13-2
13-2
MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT SCREW LISTS - MAIN UNIT
186 D3 x 10
187 D3 x 10
188 D3 x 10
212 D3 x 12
213 D3 x 12
214 D3 x 12
215 D3 x 12
226 M3 x 6
227 M3 x 6
228 M3 x 6
229 M3 x 6
230 D3 x 10
231 M3 x 10
276 D3 x 12
277 M3 x 10
278 D3 x 10
279 D3 x 16
280 D3 x 8
281 D3 x 10
282 D3 x 10
283 D3 x 10
284 D3 x 10
285 D3 x 10
286 D3 x 10
287 D3 x 10
288 D3 x 10
292 D3 x 10
293 D3 x 20
295 D2 x 8
296 D3 x 10
297 D3 x 10
298 D3 x 10
299 D3 x 10
300 D3 x 10
301 D3 x 10
302 D3 x 10
303 D3 x 10
304 D3 x 12
1101-34 D3 x 10
1101-36 D3 x 10
1102-33 D3 x 10
1103-33 D3 x 10
1103-35 D3 x 10
101 3139 118 14890 Cabinet Front /22
101 3139 118 15150 Cabinet Front /37
105 3139 118 14920 Button Set DTC Chrome
106 3139 118 14910 Cover Tray DTC
107 4822 459 11086 Badge Assembly Philips
124 3139 118 15030 Window Display /22
124 3139 118 15160 Window Display /37
125 3139 114 71610 Lightguide Wash
126 3139 114 71620 Housing Lightguide Wash
127 3139 118 15010 Button Set Power Chrome
130 3139 114 71770 Button Set Source
131 3139 118 14990 Cap Source Micro Chrome
133 3139 118 14960 Button Set Control Left
134 3139 118 14970 Button Set Control Right
135 3139 118 14980 Button Set Treble/Bass
136 3139 118 14950 Knob Jog Chrome
137 3139 118 14930 Cover Display
141 3139 113 27010 Filter Blue
158 3139 118 15020 Cover Cassette
159 3139 118 15050 Window Cassette
189 * 3139 118 15780 Plate Transport DTC
198 3139 114 68620 Door Cassette Left
200 4822 529 10322 Damper Assembly
201 3139 114 68640 Push Catch Left
203 4822 492 11344 Spring Compression
205 4822 402 11245 Bracket Left
207 3139 111 01390 Spring Torsion Left
209 4822 492 42787 Spring Cassette
246 3139 113 27140 Foot Rubber (SQ) 4mm
252 3139 114 71560 Bracket Combi
253 3139 114 71510 Panel Left Micro
254 3139 114 71520 Panel Right Micro
255 3139 114 71530 Cover Top Micro
256 3139 114 71490 Panel Rear Micro
271 3139 114 71010 Stopper Heatsink
350 3139 118 78510 Loudspeaker Box /22
350 3139 118 78500 Loudspeaker Box /37
9965 000 07825 Loud. Cloth Frame assembly
351 4822 303 50063 FM Aerial /22
351 4822 303 11094 FM Antenna Wire /37
356 3139 118 78610 Remote Control /22
356 3139 118 78620 Remote Control /37
384 4822 303 50082 AM Frame
385 4822 321 10249
!
Mains Cord /22
385 4822 321 11466
!
Mains Cord /37
387 3139 115 20740 Instruction For Use /22
387 3139 115 20750 Instruction For Use /37
1110 4822 361 11161 Cooling Fan KD1206PTS3
1131 3139 110 35560 Flex Cable 19pin 18cm AD
1133 3139 110 35570 Flex Cable 9pin 10cm AD
1134 3139 110 35240 Flex Cable 8pin 28cm AD
1135 3139 110 35230 Flex Cable 7pin 22cm AD
1136 4822 320 12752 Flex Cable 7pin 18cm AD
1137 3139 110 35250 Flex Cable 4pin 12cm AD
1138 3139 110 35520 Flex Cable 19pin 10cm AD
1141 4822 320 12752 Flex Cable 7pin 18cm AD
1142 3139 110 34610 Flex Cable 11pin 18cm AD
1143 3139 110 34950 Flex Cable 07p/120/07p Ad
5001 3139 118 32340
!
Mains Transformer /22
5001 3139 118 32330
!
Mains Transformer /37
Note: Only the parts mentioned in this list are normal
service spare parts.
* Pos 189 is used for transportation only, it must be
removed before playing CD.
