11-5
ELECTRICAL PARTS LIST - MAINS BOARD
MISCELLANEOUS
1100 4822 265 31015
!
Mains Socket /22
1100 2422 030 00328
!
Mains Socket /37
1102 4822 280 10382
!
Relay 1P 9V
1106 4822 071 54002
!
Fuse T4A 250V /22
1106 4822 071 55002
!
Fuse T5A 250V /37
1107 4822 071 54002
!
Fuse T4A 250V /22
1107 4822 071 55002
!
Fuse T5A 250V /37
1202 4822 267 10953 Flex Socket 7pin Vert.
CAPACITORS
2100 4822 122 33449 47nF 30% 50V
2101 4822 122 33449 47nF 30% 50V
2102 4822 124 40255 100µF 20% 63V
2106 4822 121 43526 47nF 5% 250V
2107 4822 124 40255 100µF 20% 63V
2108 4822 124 81151 22µF 20% 50V
2110 5322 121 42386 100nF 5% 63V
2111 5322 121 42386 100nF 5% 63V
2112 5322 121 42386 100nF 5% 63V
2114 4822 124 12328 6800µF 20% 16V
2115 4822 124 80563 4700µF 20% 35V
RESISTORS
3103 4822 052 10109
!
10R 5% 0,33W
3105 4822 050 11002 1k 1% 0,4W
3106 4822 050 11002 1k 1% 0,4W
3110 4822 117 12148
!
1R5 5% 0,33W
3111 4822 116 52276 3k9 5% 0,5W
3112 4822 116 52256 2k2 5% 0,5W
3113 4822 050 23303 33k 1% 0,6W
3114 4822 053 21106
!
10M 5% 0,5W
3115 4822 116 52238 12k 5% 0,5W
COILS & FILTERS
5100 3103 308 30610
!
Standby Transformer /22
5107 4822 157 11832 Mains Filter 400µH 3A
DIODES
6100 4822 130 30621 1N4148
6104 4822 130 31878 1N4003G
6105 4822 130 31878 1N4003G
6106 4822 130 31878 1N4003G
6107 4822 130 31878 1N4003G
6110 4822 130 30621 1N4148
6111 4822 130 30621 1N4148
6112 4822 130 30621 1N4148
6113 4822 130 30621 1N4148
6115 4822 130 34382 BZX79-B8V2
6116 4822 130 31878 1N4003G
6117 4822 130 34142 BZX79-B33
6118 4822 130 82078 D5SBA20
6119 4822 130 30621 1N4148
6120 4822 130 30621 1N4148
TRANSISTORS
7003 4822 130 40981 BC337-25
7005 4822 130 41246 BC327-25
Note: Only the parts mentioned in this list are normal
service spare parts.
