ELECTRICAL PARTS LIST - COMBI BOARD
RESISTORS
4571 4822 051 20008 0R Jumper 0805
4572 4822 051 20008 0R Jumper 0805
4573 4822 051 20008 0R Jumper 0805
4575 4822 051 20008 0R Jumper 0805
4576 4822 051 20008 0R Jumper 0805
4577 4822 051 20008 0R Jumper 0805
4578 4822 051 20008 0R Jumper 0805
4579 4822 051 20008 0R Jumper 0805
4580 4822 051 20008 0R Jumper 0805
4581 4822 051 20008 0R Jumper 0805
4582 4822 051 20008 0R Jumper 0805
4583 4822 051 20008 0R Jumper 0805
4584 4822 051 20008 0R Jumper 0805
4585 4822 051 20008 0R Jumper 0805
4586 4822 051 20008 0R Jumper 0805
4587 4822 051 20008 0R Jumper 0805
4588 4822 051 20008 0R Jumper 0805
4589 4822 051 20008 0R Jumper 0805
COILS & FILTERS
5200 4822 157 11837 Coil 8,5 Turn 0,36µH 10%
5201 4822 157 11837 Coil 8,5 Turn 0,36µH 10%
5202 4822 157 11837 Coil 8,5 Turn 0,36µH 10%
5203 4822 157 11837 Coil 8,5 Turn 0,36µH 10%
5500 4822 157 62552 Coil 2,2µH 5%
5501 2422 536 00019 Transformer 6RG
DIODES
6200 4822 130 31878 1N4003G
6201 4822 130 31878 1N4003G
6202 4822 130 31878 1N4003G
6203 4822 130 31878 1N4003G
6204 9340 550 66112 BYV28-200/24
6205 4822 130 34441 BZX79-B22
6206 4822 130 30621 1N4148
6207 4822 130 34174 BZX79-B4V7
6208 4822 130 31024 BZX79-B18
6209 4822 130 34174 BZX79-B4V7
6508 4822 130 61219 BZX79-B10
6509 4822 130 30621 1N4148
6510 4822 130 30862 BZX79-B9V1
6511 4822 130 30621 1N4148
6512 4822 130 30621 1N4148
6513 4822 130 31878 1N4003G
6520 4822 130 30621 1N4148
TRANSISTORS & INTEGRATED CIRCUITS
7200 9322 133 18682 AN7125P
7201 4822 130 44568 BC557B
7202 4822 130 44568 BC557B
7203 4822 130 40959 BC547B
7204 4822 130 10847 BDW94C
7205 4822 130 40959 BC547B
7206 4822 130 44568 BC557B
7506 4822 130 60373 BC857B
7507 4822 130 60511 BC847B
7509 4822 130 60511 BC847B
7510 4822 209 31378 NJM4556MB
7511 4822 130 42804 BC817-25
7512 4822 130 42804 BC817-25
7514 4822 130 42804 BC817-25
7515 4822 130 42804 BC817-25
7516 4822 130 60373 BC857B
7517 4822 130 60511 BC847B
7518 4822 130 60511 BC847B
7519 4822 130 60373 BC857B
7520 4822 130 60511 BC847B
7521 4822 130 60511 BC847B
7522 4822 130 42804 BC817-25
7523 4822 130 42804 BC817-25
7524 4822 130 60373 BC857B
7525 4822 209 17235 74LVU04D
7526 4822 209 17345 M62320FP
7527 4822 130 41246 BC327-25
7528 4822 130 60511 BC847B
7529 4822 209 72042 MC78L05ACP
7540 4822 130 42804 BC817-25
7541 4822 130 42804 BC817-25
7550 9322 150 74668 TDA7468D
7553 4822 130 60511 BC847B
7555 4822 130 60511 BC847B
7556 4822 130 60511 BC847B
Note: Only the parts mentioned in this list are normal
service spare parts.
