Alignments
EN 46 Q552.2E LA6.
2011-Jun-01
back to
div. table
Bit 11 2048 Ambient Light 0000
1)
0000 = none
0001 = 2-sided (3/3)
0010 = 2-sided (4/4)
0011 = 2-sided (5/5)
0100 = 2-sided (6/6)
0101 = 2-sided (7/7)
0110 = 3-sided (5/5/5)
0111 = 3-sided (6/6/6)
1000 = 3-sided (3/6/3)
1001 = 3-sided (6/9/6)
1010 = 2-sided (8/8)
1011 = 3-sided (4/4/4)
1100 = 2-sided (1/1)
1101 = 2-sided (2/2)
1110 = future use
1111 = future use
Bit 10 1024
Bit 9 512
Bit 8 256
Bit 7 128 FPGA3Dact/1Ddimm 0
1)
0 = OFF
1 = ON
Bit 6 64 AL Select 0
1)
0 = AL2k10
1 = AL2k11
Bit 5 32 3D Passive 0
1)
0 = 2D
1 = 3D passive
Bit 4 16 Smart Bit Enhancement (SBE) 0
1)
0 = off
1 = on (200 Hz board present)
Bit 3 8 Super Resolution 0
1)
0 = Super Resolution SD
1 = Super Resolution HD
Bit 2 4 Light Sensor LUT 00
1)
00 = Lut 0
01 = Lut 1
10 = Lut 2
11 = Lut 3
Bit 1 2
Bit 0 (LSB) 1 Light Sensor 1
1)
0 = OFF
1 = ON
Option 3 (prescribed value 15421
1)
)
Bit 15 (MSB) 32768 Side IO 0
1)
0 = not present
1 = present
Bit 14 16384 AV3 011
1)
000 = none
001 = CVBS
010 = YPbPr
011 = YPbPr/LR
100 = YPbPr/HV/LR
101 = CVBS/LR
110 = CVBS/Yc/LR
111 = future use
Bit 13 8192
Bit 12 4096
Bit 11 2048 AV2 11
1)
00 = Scart/CVBS/RGB/LR
01 = CVBS/LR
10 = YPbPr/LR
11 = none
Bit 10 1024
Bit 9 512 AV1 00
1)
00 = Scart/CVBS/RGB/LR
01 = CVBS/YC/YPbPr/HV/LR
10 = CVBS/YC/YPbPr/LR
11 = YPbPr/LR
Bit 8 256
Bit 7 128 3D Prepared 0
1)
0 = not prepared
1 = prepared
Bit 6 64 Sound in Stand 0
1)
0 = Sound in Cabinet
1 = Sound in Stand
Bit 5 32 Headphone 1
1)
0 = OFF
1 = ON
Bit 4 16 Seamless System 1
1)
0 = OFF
1 = ON
Bit 3 8 ViewPort 21_9/PQL 1
1)
0 = OFF
1 = ON
Bit 2 4 HDMI Side 1
1)
0 = OFF
1 = ON
Bit 1 2 HDMI 3 0
1)
0 = OFF
1 = ON
Bit 0 (LSB) 1 HDMI 2 1
1)
0 = OFF
1 = ON
Option 4 (prescribed value 02235
1)
)
Bit 15 (MSB) 32768 Cabinet 00001
1)
Cabinet type
(no detailed info available)
Bit 14 16384
Bit 13 8192
Bit 12 4096
Bit 11 2048
Bit 10 1024 Region 000
1)
000 = Europe (/02, /05 & /12)
001 = AP PAL multi
010 = AP NTSC
011 = Russian (/60)
100 = Latam (/78 & /77)
101 = Australia
110 = China (/93)
111 = future use
Bit 9 512
Bit 8 256
Bit 7 128 Display MSB 1
1)
0 = display option =< 255
1 = display option > 255
Bit 6 64 S Video 0
1)
0 = OFF
1 = ON
Bit 5 32 Video Store SD Card 1
1)
0 = OFF
1 = ON
Bit 4 16 Internet SW Upgrade 1
1)
0 = OFF
1 = ON (automatic software upgradable via internet)
Bit 3 8 Online Service 1
1)
0 = OFF
1 = ON (connection to internet provider Philips)
Option & Bit Dec. Value Option Name Prescribed Value
1)
Description
