FL MGUARD PCI(E)4000
212
PHOENIX CONTACT 105656_en_05
9.9 Technical data
Hardware properties FL MGUARD PCI4000 | FL MGUARD PCIE4000
Platform Freescale network processor with 330 MHz clocking
Network interfaces 1 LAN port | 1 WAN port
Ethernet IEEE 802.3 10/100 Base TX |
RJ45 | full duplex | auto MDIX
Other interfaces Serial RS-232, internal connector
Memory 128 MB RAM | 128 MB Flash SD card | replaceable configuration memory
Drives –
Redundancy options Optional: VPN | router
Power supply 3.3 V or 5 V
via PCI (FL MGUARD PCI4000) or PCI Express bus
(FL MGUARD PCIE4000)
Power consumption Typical, 3.7 W ... 4.2 W
Humidity range 5% ... 95% during operation and storage, non-condensing
Degree of protection Depending on installation type and on the host system
Temperature range Without battery (HT version)
With battery
0°C ... +70°C (operation)
-20°C ... +70°C (storage)
0°C ... +60°C (operation)
-20°C ... +60°C (storage)
Dimensions (H x W x D) 95 mm X 18 mm X 130 mm
Weight 131 g
Weight (incl. packaging) 200 g
Firmware and power values FL MGUARD PCI4000 | FL MGUARD PCIE4000
Firmware compatibility For mGuard v7.5.0 or later: Phoenix Contact recommends the use of the lat-
est firmware version and patch releases in each case.
For the scope of functions, please refer to the relevant firmware data sheet.
Data throughput (Firewall) Router mode, default firewall rules, bidirectional throughput: max. 120 Mbps
Stealth mode, default firewall rules, bidirectional throughput: max. 50 Mbps
Hardware-based encryption DES | 3DES | AES-128/192/256
Data throughput encrypted (IPsec VPN) Router mode, default firewall rules, bidirectional throughput: max. 30 Mbps
Stealth mode, default firewall rules, bidirectional throughput: max. 20 Mbps
Management support Web GUI (HTTPS) | command line interface (SSH) | SNMP v1/2/3 | central
device management software
Diagnostics LEDs (2 x LAN, 2 x WAN in combination) for Ethernet status and speed; 1
LED for Power, Error, State, Fault, Info) | log file | remote-syslog
Other FL MGUARD PCI4000 | FL MGUARD PCIE4000
Conformance CE | FCC
Special features Realtime clock | Trusted Platform Module (TPM) | temperature sensor |
mGuard Remote Services Portal ready
