FL MGUARD CENTERPORT
246
PHOENIX CONTACT 105656_en_05
11.9 Technical data
Hardware properties FL MGUARD CENTERPORT
Platform Multi-core x86 processor architecture
Network interfaces 1 LAN port | 1 WAN port | 1 SYNC port | 1 DMZ port
Ethernet IEEE 802.3 10/100/1000 Base TX |
RJ45 | full/half duplex | auto MDIX
Other interfaces VGA console | serial RS-232,
D-SUB 9 connector | 6 x USB
Drives 1 HDD | 1 SD card
Redundancy options Optional VPN license | router and firewall
Power supply 2 x 100 V AC ... 240 V AC, 300 W at 50/60 Hz, redundant
Power consumption Dependent on the expansion stage
Humidity range 20% ... 90% during operation, non-condensing
10% ... 90% out of service
Degree of protection Front IP20
Temperature range 0°C ... +45°C (operation)
-20°C ... +70°C (storage)
Dimensions (H x W x D) 44 mm x 447 mm x 458 mm (1 HU x 19'' x 18.5'')
Weight 17 kg
Firmware and power values FL MGUARD CENTERPORT
Firmware compatibility mGuard v8.1.2 or later;
Phoenix Contact recommends using the latest patch releases;
For the scope of functions, please refer to the relevant firmware data sheet.
Data throughput (router | firewall) 2,000 Mbps bidirectional | 2,000 Mbps bidirectional
When using the DMZ as independent network zone, the maximum possible
data throughput is distributed to the three zones.
Hardware-based encryption DES | 3DES | AES-128/192/256
Data throughput encrypted (IPsec VPN) 600 Mbps bidirectional (router mode)
When using the DMZ as independent network zone, the maximum possible
data throughput is distributed to the three zones.
Management support Web GUI (HTTPS) | command line interface (SSH) | SNMP v1/2/3 |
central device management software
Diagnostics Dot matrix display | LEDs | boot menu | log file | remote Syslog
Other FL MGUARD CENTERPORT
Conformance FCC, CE, developed according to UL requirements
