FL MGUARD DELTA TX/TX
105656_en_05 PHOENIX CONTACT 263
12.10 Technical data
Hardware properties FL MGUARD DELTA TX/TX
Platform Freescale network processor
with 330 MHz clocking
Network interfaces 1 LAN port | 1 WAN port
Ethernet IEEE 802.3 10/100 Base TX |
RJ45 | full duplex | auto MDIX
Other interfaces Serial RS-232, D-SUB 9 connector
Memory 128 MB RAM | 128 MB Flash
SD card, replaceable configuration memory
Redundancy options Optional: VPN | router
Power supply External power supply unit 12 V/0.85 A DC | 100 – 240 V/0.4 A AC
Power consumption 2.13 W, typical
Humidity range 5% ... 95% during operation, non-condensing
Degree of protection IP20
Temperature range 0°C ... +40°C (operation)
0°C ... +60°C (storage)
Dimensions (H x W x D) 45 x 130 x 114 mm
Weight 725 g
Weight (incl. packaging) 1025 g
Firmware and power values FL MGUARD DELTA TX/TX
Firmware compatibility For mGuard v7.4.0 or later: Phoenix Contact recommends the use of the lat-
est firmware version and patch releases in each case.
For the scope of functions, please refer to the relevant firmware data sheet.
Data throughput (Firewall) Router mode, default firewall rules, bidirectional throughput: max. 120 Mbps
Stealth mode, default firewall rules, bidirectional throughput: max. 50 Mbps
Virtual Private Network (VPN) IPsec (IETF standard), VPN models up to 10 tunnels,
Optionally up to 250 VPN tunnels
Hardware-based encryption DES | 3DES | AES-128/192/256
Data throughput encrypted (IPsec VPN) Router mode, default firewall rules, bidirectional throughput: max. 30 Mbps
Stealth mode, default firewall rules, bidirectional throughput: max. 20 Mbps
Management support Web GUI (HTTPS) | command line interface (SSH) | SNMP v1/2/3 | central
device management software
Diagnostics LEDs (Power, State, Error, Signal, Fault, Info) | log file | remote syslog
Other FL MGUARD DELTA TX/TX
Conformance CE | FCC
Special features Realtime clock | Trusted Platform Module (TPM) | temperature sensor |
mGuard Remote Services Portal ready
