FL MGUARD SMART2
228
PHOENIX CONTACT 105656_en_05
10.9 Technical data
Hardware properties FL MGUARD SMART2
Platform Freescale network processor
with 330 MHz clocking
Network interfaces 1 LAN port | 1 WAN port
Ethernet IEEE 802.3 10/100 Base TX |
RJ45 | full duplex | auto MDIX
Other interfaces Serial via USB connection
Drives –
Redundancy options Depending on the firmware used
Power supply Via USB interface (5 V at 500 mA)
Optional: external power supply unit (110 V ... 230 V)
Power consumption 2.5 W, maximum
Temperature range 0°C ... +40°C (operation)
-20°C ... +60°C (storage)
Humidity range 20% ... 90% during operation, non-condensing
Degree of protection IP30
Dimensions (H x W x D) 27 x 77 x 115 mm
Weight 185 g
Firmware and power values FL MGUARD SMART2
Firmware compatibility For mGuard v7.2 or later: Phoenix Contact recommends the use of the latest
firmware version and patch releases in each case.
For the scope of functions, please refer to the relevant firmware data sheet.
Data throughput (Firewall) Router mode, default firewall rules, bidirectional throughput: max. 120 Mbps
Stealth mode, default firewall rules, bidirectional throughput: max. 50 Mbps
Hardware-based encryption DES | 3DES | AES-128/192/256
Data throughput encrypted (IPsec VPN) Router mode, default firewall rules, bidirectional throughput: max. 30 Mbps
Stealth mode, default firewall rules, bidirectional throughput: max. 20 Mbps
Management support Web GUI (HTTPS) | command line interface (SSH) | SNMP v1/2/3 | central
device management software
Diagnostics 3 LEDs (in combination for boot process, heartbeat, system error, Ethernet
status, Recovery mode) | Log File | Remote Syslog
Other FL MGUARD SMART2
Conformance CE | FCC
Special features Realtime clock | Trusted Platform Module (TPM) | temperature sensor
