FL MGUARD RS4000 TX/TX-P
140
PHOENIX CONTACT 105656_en_05
6.11 Technical Data
Hardware properties FL MGUARD RS4000 TX/TX-P
Platform Freescale network processor with 330 MHz clocking
Network interfaces 1 LAN port | 1 WAN port
Ethernet IEEE 802.3 10/100 Base TX
RJ45 | full duplex | auto MDIX
Other interfaces Serial RS-232 | D-SUB 9 plug
2 digital inputs and 2 digital outputs each
Memory 128 MB RAM | 128 MB Flash | SD card
Replaceable configuration memory
Redundancy options VPN | router and firewall
Power supply Voltage range 11 ... 36 V DC, redundant
Power consumption 2.13 W, typical
Humidity range 5 %... 95% (operation, storage), non-condensing
Degree of protection IP20
Temperature range -40°C... +70°C (operation)
-40°C... +70°C (storage)
Dimensions (H x W x D) 130 x 45 x 114 mm (up to DIN rail support)
Weight 730 g (TX/TX)
Weight (incl. packaging) 892 g (TX/TX)
Firmware and power values FL MGUARD RS4000 TX/TX-P
Firmware compatibility For mGuard v8.1.0 or newer: Phoenix Contact recommends the use of the lat-
est firmware version and patch releases. For the scope of functions, please
refer to the relevant firmware data sheet.
Data throughput (Firewall) Router mode, default firewall rules, bidirectional throughput: max. 120 Mbps
Stealth mode, default firewall rules, bidirectional throughput: max. 50 Mbps
Virtual Private Network (VPN) IPsec (IETF standard)
Up to 250 VPN tunnels
Hardware-based encryption DES | 3DES | AES-128/192/256
Data throughput encrypted (IPsec VPN) Router mode, default firewall rule, bidirectional throughput: max. 30 Mbps
Stealth mode, default firewall rule, bidirectional throughput max. 20 Mbps
Management support Web GUI (HTTPS) | command line interface (SSH) | SNMP v1/2/3 | central
device management software
Diagnostics LEDs (Power 1 + 2, State, Error, Signal, Fault, Modem, Info) signal contacts |
service contacts | log file | remote syslog
