FL MGUARD RS4004/RS2005
105656_en_05 PHOENIX CONTACT 53
2.10 Technical data
Hardware properties FL MGUARD RS4004 FL MGUARD RS2005
Platform Freescale network processor Freescale network processor
Network interfaces 4 LAN ports (managed) | 1 DMZ port |
1WAN port
Ethernet IEEE 802.3 10/100 Base TX
RJ45 | full duplex | auto MDIX
5 LAN ports (unmanaged)
Ethernet IEEE 802.3 10/100-BaseTX
RJ45 | full duplex | auto MDIX
Other interfaces Serial RS-232 | D-SUB 9 connector
3 digital inputs and 3 digital outputs
Serial RS-232 | D-SUB 9 connector
3 digital inputs and 3 digital outputs
Memory 128-Mbyte RAM | 128-Mbyte Flash
SD card
Replaceable configuration memory
128-Mbyte RAM | 128-Mbyte Flash
SD card
Replaceable configuration memory
Redundancy options Optional: VPN | router and firewall –
Power supply Voltage range 11 ... 36 V DC, redundant Voltage range 11 ... 36 V DC
Current consumption Typical < 200 mA (24 V DC) |
Maximum < 800 mA (10 V DC)
Typical < 200 mA (24 V DC) |
Maximum < 800 mA (10 V DC)
Humidity range 5% ... 95% (operation, storage), non-con-
densing
5% ... 95% (operation, storage), non-con-
densing
Degree of protection IP20 IP20
Temperature range -20°C ... +60°C (operation)
-20°C ... +70°C (storage)
-20°C ... +60°C (operation)
-20°C ... +70°C (storage)
Dimensions (H x W x D) 130 mm x 45 mm x 114 mm
(up to DIN rail support)
130 mm x 45 mm x 114 mm
(up to DIN rail support)
Weight 749 g (TX/DTX) 749 g (TX)
Weight (incl. packaging) 906 g (TX/DTX) 906 g (TX)
Firmware and power values FL MGUARD RS4004 FL MGUARD RS2005
Firmware compatibility Firmware 8.1.5: Phoenix Contact recommends the use of the latest firmware version
and patch releases in each case.
For the scope of functions, please refer to the relevant firmware data sheet.
Data throughput (Firewall) Router mode, default firewall rules, bidirectional throughput: 120 Mbps, maximum
Stealth mode, default firewall rules, bidirectional throughput: 50 Mbps, maximum
When using the DMZ as independent network zone, the maximum possible data
throughput is distributed to the three zones.
Virtual Private Network (VPN) IPsec (IETF standard)
Optionally up to 250 VPN tunnels
IPsec (IETF standard)
Up to 2 VPN tunnels
Hardware-based encryption DES | 3DES | AES-128/192/256 DES | 3DES | AES-128/192/256
Data throughput encrypted (IPsec VPN) Router mode, default firewall rules, bidirectional throughput: 30 Mbps, maximum
Stealth mode, default firewall rules, bidirectional throughput: 20 Mbps, maximum
When using the DMZ as independent network zone, the maximum possible data
throughput is distributed to the three zones.
Management support Web GUI (HTTPS) | command line interface (SSH) | SNMP v1/2/3 | central device man-
agement software
Diagnostics 13 LEDs (Power 1 + 2, State, Error, Signal, Fault, Modem, Info, Signal Status, SIM Sta-
tus) | service I/O | log file | remote Syslog
Other FL MGUARD RS4004 FL MGUARD RS2005
Special features Realtime clock | Trusted Platform Module (TPM) | temperature sensor | mGuard Se-
cure Cloud ready
