FL MGUARD CENTERPORT
105656_en_05 PHOENIX CONTACT 245
Start rescue procedure from SD Card
Requirement: The firmware of the mGuard has been previously copied to the SD card:
/Firmware/install.x86_64.p7s
/Firmware/firmware.img.x86_64.p7s
Effect: The mGuard device downloads all necessary files from the inserted SD card.
With this in mind, while the boot menu is displayed at the latest and before applying this
selection, insert the SD card with the stored firmware into the device. (For security rea-
sons, the FL MGUARD CENTERPORT does not boot from an SD card).
– Once the rescue procedure is complete, a corresponding message appears on the
monitor. Follow any further on-screen instructions.
The device is in the delivery state. You can now configure it again (see “Establishing a local
configuration connection” on page 237):
Burning the mGuard firmware to CD/DVD-ROM
The firmware for the mGuard can be burnt to CD/DVD. A zip file is available for download
from the download page of
phoenixcontact.net/products.
Burn the content of this zip archive as a data CD/DVD. The following files must be located
in the following folders/under the following path names on the CD/DVD:
– /Firmware/install.x86_64.p7s
– /Firmware/firmware.img.x86_64.p7s
