BAUDRATE COMMANDS
Table 7 Baudrate Commands
Command
Optional
Payload
Description
baudrate
Displays the current console baud rate and help for this
command
baudrate
921600
460800
230400
115200
57600
38400
28800
19200
9600
Sets the console baudrate to the payload value. A carriage
return must be sent to the camera within 20 sec of this
command using the new baudrate to acknowledge the change.
To save the new baudrate as power on default, “save flash
<cr>” must be entered at the console.
ANALOG VIDEO COMMANDS
Table 8 Analog Video Commands
Command
Optional
Payload
Description
av gamma
x.xxx
Sets the gamma value for the analog video output channel
av power
0
1
Turns off the analog video output channel
Turns on the analog video output channel
av set
NTSC
PAL
Sets the analog video output to NTSC format
Sets the analog video output to PAL format
av tp
0
1
2
Turns off the analog video test pattern
Turns on the analog video channel test pattern
Turns on the internal analog video chip test pattern
CAMERA LINK VIDEO COMMANDS
Table 9 Camera Link Video Commands
Command
Optional
Payload
Description
cl gamma
x.xxx
Sets the gamma value for the digital video output channel
av power
0
1
Turns off the digital video output channel
Turns on the digital video output channel
