3. SPECIFICATIONS
Detailed specifications of the NOCTURN XL camera are given in Table 2.
Table 2 NOCTURN XL Specifications
Parameter
Specification
Sensor Resolution
1280 × 1024 Pixels
Sensor Pixel Pitch
9.7 µm × 9.7 µm
Sensor Well Capacity
> 25000 e-
Sensor Dynamic Range
> 60 dB (> 72 dB by using the HDR
3
mode)
Sensor Read Noise
< 4 e- med. (at 60Hz frame rate)
Sensor Quantum Efficiency
> 50% at 600nm (see Figure 3)
Frame Rate
50, 60 or 100Hz with full field resolution
4
(user adjustable)
Sensor Image Lag
< 0.1 %
Sensor Shutter Mode
Rolling
Lens Mount
CS
Dimensions (Width × Height × Depth
5
)
34.1 mm × 36.6 mm × 37.4 mm
Weight
85 grams
Digital Video Output
10/8 bit CameraLink® Compatible
Analog Video Output
NTSC/PAL (user configurable)
Communications
Serial via CameraLink® Interface or USB interface
Image Correction
Bad pixel replacement and 2 points non uniformity correction
Synchronization
Analog output strobe reference
Camera/Imaging Start Up Time
< 5 seconds
Gain Control
Automatic (AGC) or manual
Digital Zoom
Up to 4 X
6
Contrast Enhancement
Contrast stretching and histogram equalization
Operating Temperature
-40° to +60° C
Storage Temperature
-50° to +80° C
Input Voltage
USB powered or external +5 to +15 VDC
Power (Typical)
7
60/50Hz Mode: < 1.8 W; 100Hz Mode: < 2.25W
3
HDR : High Dynamic Range
4
Lower frame rate can be achieved by increasing integration time
5
Excludes connectors protruding from main NOCTURN XL housing
6
Digital zoom is only enabled in 50, 60 and 30Hz modes
7
Digital video output only without advanced image processing
