PHOTONIS Nocturn - Nuc Commands

PHOTONIS | 20
NVT 200-LC-0103
Revision: D
Page 20 of 43
Command
Optional Payload
Description
Setting
lgtransup
xx
Integration time (in lines) to set the sensor to when
transitioning from the “Low Gain” to the “Medium Gain”
Setting
m0gain
xx
Gain value used for the “Medium Gain” setting
m0gmin
xx
Minimum integration time (in lines) of the “Medium Gain”
setting
m0gmax
xx
Maximum integration time (in lines) of the “Medium Gain”
setting
m0gtransdn
xx
Integration time (in lines) to set the sensor to when
transitioning from the “High Gain” to the “Medium Gain”
Setting
m0gtransup
xx
Integration time (in lines) to set the sensor to when
transitioning from the “Medium Gain” to the “High Gain”
Setting
mingain
[0-7]
Adjusts the sensor minimum gain value
maxgain
[0-7]
Adjusts the sensor maximum gain value
gain
xx
Sets the camera gain to x if the AGC is diabled
mfongain
xx
Gain value to use to automatically turn on the median filter
(video mf must be set to 2). This setting is used in conjunction
with mfonexp.
mfoffgain
xx
Gain value to use to automatically turn off the median filter
(video mf setting in the Video Pipeline menu must be set to
2). This setting is used in conjunction with mfoffexp.
mfonexp
xx
Exposure (in lines) to use to automatically turn on the median
filter (video mf setting in the Video Pipeline menu must be set
to 2). This setting is used in conjunction with mfongain.
mfoffexp
xx
Exposure (in lines) to use to automatically turn off the median
filter (video mf in the Video Pipeline menu must be set to 2).
This setting is used in conjunction with mfoffgain.
minbins
xx
Minimum number of bins used to stretch the image if contrast
stretching is enabled.
NUC COMMANDS
A full list of the NUC (non-uniformity correction) related commands can be displayed on the console by
sending “nuc <cr>” at the console terminal. Each command in Table 14 should be preceded by “nuc”
before being sent to the camera. The NUC can be simply enables/disabled by entering the following
commands at the console terminal:
 Enable non-uniformity correction
o Send:
nuc on <cr>
o Receive:
gain and offset nuc tables enabled
OK
>
