17 | User Reference Guide NOCTURN XL Camera
NVT 200-LC-0103
Revision: D
Page 17 of 43
TEMPERATURE DISPLAY COMMANDS
Table 10 Temperature Display Commands
Command
Optional
Payload
Description
temp rd
xx
Reads temperature sensor register xx (0 is currently the default
on the NOCTURN camera)
temp wr
xx dd
Writes the temperature register xx with value dd
FILE TRANSFER COMMANDS
Table 11 FIle Transfer Commands
Command
Optional
Payload
Description
receive
[filename]
Xmodem/Ymodem receive file from PC.
[filename] is the flash filename to write.
send
-x [filename]
-y [filename]
Sends [filename] using Xmodem1k protocol
Sends [filename] using Ymodem1k protocol
[filename] is the flash filename to send
VIDEO PIPELINE COMMANDS
Table 12 Video Pipeline Commands
Command
Optional Payload
Description
video agc
0
1
Automatic gain and exposure control disabled
Automatic gain and exposure control enabled
Use agc status to see agc loop variables
video bpp
0
1
Sets the digital video output to 10bits per pixel
Sets the digital video output to 8bits per pixel
video contrast
0
1
2
3
4
No contrast enhancement
Histogram stretching contrast enhancement
Histogram equalization contrast enhancement
Limited/adaptive equalization contrast enhancement
Unrounded histogram equalization contrast enhancement
video hconalways
0
1
Do not applycontrast enhancement every histogram update
Service contrast enhancement every histogram update
video mf
0
1
2
Median filter turned off
Median filter turned on
Median filter turns on automatic in AGC loop
video sf
0
1
Disable the convolution filter
Enables the convolution filter
video vflip
0
1
Image output in default vertical orientation
Image output vertically inverted from default orientation
video zoom
x.x
Set the digital video zoom to x.x (1.0 to 4.0)
video framerate
0
Sets the camera video main frame rate to 60Hz
