PHOTONIS Nocturn - 7 Graphical User Interface; Installation

PHOTONIS | 26
NVT 200-LC-0103
Revision: D
Page 26 of 43
Name
Address
Size
Description
test_mode
V_TSIG
52
7
Reference voltage for the signal conversion in
test_mode
V_TEST_HIGH
53
6
Highest voltage adjustment of V_TREF and V_TSIG
V_TEST_LOW
54
6
Lowest voltage adjustment for V_TREF and V_TSIG
V_BLSUN
55
7
Voltage setting for clipping of reset in black sun
protection
TEMP
62-63
16
Temperature sensor (readout only!)
7. GRAPHICAL USER INTERFACE
Windows 7 is expressly provided for evaluation purposes only. This software, including any and all
derivative and/or modified works, is proprietary and wholly owned by PHOTONIS USA and subject to
intellectual property protection. PHOTONIS USA assumes no responsibility whatsoever for the use of
the GUI software and makes no guarantees or warranties, expressed or implied, about its quality,
reliability, compatibility, or any other characteristics. It is expressly agreed and understood that no
promises, guarantees, or warranties of any kind has been made. By installing and/or using the GUI
software, the end user agrees to abide by the terms of this document and acknowledges receipt of
notice that any redistribution, dissemination, or modification of the GUI software, in whole or in part, is
strictly prohibited.
CAUTION
Recommended minimum computer configuration for the
NOCTURN XL Evaluation GUI:
 Window 7 SPI (32/64bits)
 i5 or i7 processor
 4GB RAM memory
 256Mbytes dedicated memory on graphic card
 350MB of free hard drive space to install the software
INSTALLATION
