pop window will appear to select the directory where the NUC tables are located. Please refer to
the NOCTURN XL user guide for the default naming convention and format of these tables.
 Transfer Load NUC Tables 100fps- Use this option to upload NUC correction tables for the
100fps camera configuration. When this option is selected a pop window will appear to select
the directory where the NUC tables are located. Please refer to the NOCTURN XL user guide
for the default naming convention and format of these tables.
 Transfer: Update- This menu command is used to perform firmware/software updates for the
NOCTURN camera. After this menu option is selected a pop out window will appear for the user
to select the desired update file (file extension with *.uscr). Please refer to the NOCTURN XL
user guide for further details.
 Transfer: Execute Script- This command is meant to execute a series of command in a
scripted fashion to update the camera configuration.
Help Menu
 Help: About This Software- Displays the log-on splash screen (see Figure 8). Click the “Exit”
button to return to the main GUI screen
 Help: Camera Version Info- Returns the camera software and firmware version information
(see Figure 9). Please have this information available when contacting PHOTONIS for technical
support
 Help: Help Manual- Opens a copy of this user manual in your default web browser.
 Help: Website- Opens the NOCTURN camera website in your default web browser where you
can download updates for your NOCTURN camera.
SECTION 2: MAIN CONTROL TABS
The main control tab section allows users to navigate between the main functionality of the GUI.
Settings
This tab allows the user to set the communication interface and baud rate to the camera as well as
saving both the camera configuration and sensor configuration (for the ‘Fine Frequency Adjustment”
control, etc…). Additionally, this tab allows the user to select the camera operating frame rate and pixel
bit depth. Further details on these functions are provided in the following sections.
Main Controls
Displays the main interface controls to the camera to turn on and off the video output, adjust the
exposure time, perform digital zoom. Further details on these functions are provided in the following
sections.
AGC Controls
Displays some of the Automatic Gain Control (AGC) controls for the camera, the user should refer to
the NOCTURN XL user guide for a detailed explanation of the AGC algorithm and associated controls.
