9 Adapting Settings
C-863.12 Mercury Controller MS249E Version: 1.2.1 243
ID
Type
CL
Element
Parameter name
Description
For details, see "On-Target State" (p.
23).
0x3C
CHAR
0
Axis
Stage Name
Positioner name
Maximum 20 characters; default
value: DEFAULT_STAGE
0x3F
FLOAT
0
Axis
Settling Time (s)
Delay time for setting the on-target
state.
For details, see "On-Target State" (p.
23).
0x47
INT
0
Axis
Reference Travel
Direction
Default direction for the reference
move
For details, see "Referencing" (p.
28).
0x48
INT
0
Axis
Motor Drive Offset
Velocity-dependent offset
For details, see "Servo Algorithm
and Other Control Value
Corrections" (p. 21).
0x49
FLOAT
0
Axis
Closed-Loop
Velocity (Phys.
Unit/s)
Velocity in closed-loop operation
Limited by parameter 0xA
For details, see "Generation of
Dynamics Profile" (p. 18).
0x4A
FLOAT
0
Axis
Maximum Closed-
Loop Acceleration
(Phys. Unit/s
2
)
Maximum acceleration in closed-
loop operation
Specifies the maximum value for
parameter 0xB.
0x4B
FLOAT
0
Axis
Maximum Closed-
Loop Deceleration
(Phys. Unit/s
2
)
Maximum deceleration in closed-
loop operation
Specifies the maximum value for
parameter 0xC.
0x50
FLOAT
0
Axis
Velocity For
Reference Moves
(Phys. Unit/s)
Velocity for reference move
For details, see "Referencing" (p.
28).
0x5A
INT
0
Axis
Numerator Of The
Servo Loop Input
Factor
Numerator and denominator of the
servo-loop input factor
For details, see "Servo Algorithm
and Other Control Value
Corrections" (p. 21).
0x5B
INT
0
Axis
Denominator Of The
Servo Loop Input
Factor
0x5C
INT
0
Axis
Source Of Reference
Signal
Reference signal source for the FRF
or FED commands
For details, see "Commands and
