9 Adapting Settings
244 Version: 1.2.1 MS249E C-863.12 Mercury Controller
ID
Type
CL
Element
Parameter name
Description
Parameters for Digital Inputs" (p. 84)
and "Using Digital Input Signals as
Switch Signals" (p. 86).
0x5D
INT
0
Axis
Source Of Negative
Limit Signal
Reference signal source for the FNL
or FED commands
For details, see "Commands and
Parameters for Digital Inputs" (p. 84)
and "Using Digital Input Signals as
Switch Signals" (p. 86).
0x5E
INT
0
Axis
Source Of Positive
Limit Signal
Reference signal source for the FPL
or FED commands
For details, see "Commands and
Parameters for Digital Inputs" (p. 84)
and "Using Digital Input Signals as
Switch Signals" (p. 86).
0x5F
INT
0
Axis
Invert Digital Input
Used For Negative
Limit
Inverts the polarity of the digital
inputs that are used as the source of
the negative limit switch signal.
For details, see "Commands and
Parameters for Digital Inputs" (p. 84)
and "Using Digital Input Signals as
Switch Signals" (p. 86).
0x60
INT
0
Axis
Invert Digital Input
Used For Positive
Limit
Inverts the polarity of the digital
inputs that are used as the source of
the positive limit switch signal.
For details, see "Commands and
Parameters for Digital Inputs" (p. 84)
and "Using Digital Input Signals as
Switch Signals" (p. 86).
0x61
INT
0
Axis
Invert Direction Of
Motion For Joystick-
Controlled Axis?
Should the direction of motion for
joystick-controlled axes be inverted?
Details see "Commands and
Parameters for Joystick Control" (p.
90).
0x63
FLOAT
0
Axis
Distance Between
Limit And Hard Stop
(Phys. Unit)
Distance between the built-in limit
switch and the hard stop
For details, see "Referencing" (p.
28).
0x70
INT
0
Axis
Reference Signal
Type
Reference signal type
For details, see "Reference Switch
Detection" (p. 24).
