Steering column
Refitting
Lower and upper bearing races to frame
Lower and upper seating on the chassis
Removal
Rondella e sede superiore cuscinetto superiore
After removing the upper seating, tilt the vehicle to
a side and take out the steering tube making sure
mudflaps have been removed and the calliper dis-
connected.
Sede inferiore e superiore dal telaio
To remove the bearing seats from the chassis, use
the appropriate tool as shown in the figure.
N.B.
To remove the lower seating of the lower bearing just use a
screwdriver as a lever between the seating and the shell.
LOWER AND UPPER SEATING FROM THE CHASSIS
Titolo
Durata/Valore Testo Breve (< 4000 car.) Indirizzo Immagine
Lower and upper seating from
the chassis
Rear
Suspensions MSS Fly 50 4T
SUSP - 130
