Turn signal lights
TURN INDICATORS AND HORN
Specification
Desc./Quantity
1 Indicators switch
2 Horn button
3 Horn
4 Two (2) turn signal warning light bulbs 12V - 2W
5 4 Turn indicator bulbs 12V-10W
6 Voltage regulator
7 Key switch contacts
8 Fuse 10 A
9 Battery 12V-9Ah
Checks and inspections
In case the cause of ignition failure or malfunction
cannot be easily identified at sight, first of all re-
place the control unit by another one in operating
conditions.
Remember that the engine must be off to discon-
nect and replace the control unit.
If after replacement the vehicle starts properly, the
control unit is failing and must be replaced.
Electrical system MSS Fly 50 4T
ELE SYS - 52
