- Refill the engine with oil through the oil filling hole
located in the oil sump.
- Engine oil capacity: ~ 850 cc.
- Lock the cap manually.
N.B.
Run the engine for a couple of minutes and check the oil level
when the engine is cold. The level should always be below the
MAX mark
N.B.
For the first top-up or when servicing, add 850 cm³ of engine
oil; for any other case, add 650 cm³ and top-up, if required.
Recommended products
AGIP CITY HI TEC 4T Engine oil
SAE 5W-40 Synthetic oil that exceed the require-
ments of API SL, ACEA A3, JASO MA specifica-
tions
Locking torques (N*m)
Engine oil pre-filter cover 25 ÷ 28 Nm
Checking the ignition timing
- Turn the flywheel clockwise until its 2nd notch
coincides with the Pick-up reference mark as
shown in the figure.
Make sure that the reference point on the camshaft
command crown is aligned with the reference point
on the head as shown in the second figure.
If the reference is opposite the indicator on the
head, turn the crankshaft once more as the piston
must be at the TDC of the bursting phase.
N.B.
TIME THE TIMING SYSTEM UNIT AS DESCRIBED IN CHAP-
TER 6 IF IT IS NOT IN PHASE
MSS Fly 50 4T Maintenance
MAIN - 35
