PIAGGIO MSS Fly 50 4T User Manual

Piston rings
SEAL RINGS
Name Description Dimensions Initials Quantity
1st Compression ring 39 x 1 A 0.08 ÷ 0.20
2nd Compression ring 39 x 1 A 0.05 ÷ 0.20
Oil scraper ring 39 x 2 A 0.20 ÷ 0.70
1st Compression ring
1st Oversize
39.2 x 1 A 0.08 ÷ 0.20
2nd Compression ring
1st Oversize
39.2 x 1 A 0.05 ÷ 0.20
Oil scraper ring 1st
Oversize
39.2 x 2 A 0.20 ÷ 0.70
1st Compression ring
2nd Oversize
39.4 x 1 A 0.08 ÷ 0.20
2nd Compression ring
2nd Oversize
39.4 x 1 A 0.05 ÷ 0.20
Oil scraper ring 2nd
Oversize
39.4 x 2 A 0.20 ÷ 0.70
1st Compression ring
3rd Oversize
39.6 x 1 A 0.08 ÷ 0.20
2nd Compression ring
3rd Oversize
39.6 x 1 A 0.05 ÷ 0.20
Oil scraper ring 3rd
Oversize
39.6 x 2 A 0.20 ÷ 0.70
Characteristics MSS Fly 50 4T
CHAR - 14
