Refitting
- When refitting, tighten the nuts to the prescribed torque.
- Bleed the system.
N.B.
WHILE REFITTING, REPLACE THE COPPER GASKETS ON THEIR FITTINGS.
Locking torques (N*m)
Oil bleed screw 7 ÷ 10 Calliper tightening screw 24 ÷ 27 Brake fluid pipe-calliper fitting 19 ÷ 24
See also
Front
Front brake disc
Removal
- Remove the front wheel undoing the axle clamp-
ing.
- Undo the five disc clamps.
Locking torques (N*m)
Disc tightening screw 8 ÷ 10
Refitting
-When refitting, position the disc correctly making sure that it rotates in the right direction.
Locking torques (N*m)
Disc tightening screw 8 - 12
Braking system MSS Fly 50 4T
BRAK SYS - 136

PIAGGIO MSS Fly 50 4T Specifications

General

Power Output RPM	7, 500 rpm
Torque	3.2 Nm
Fuel System	Carburetor
Rear Brake	Drum
Seat Height	760 mm
Fuel Tank Capacity	6.5 liters
Front Suspension	Telescopic fork
Rear Suspension	Hydraulic shock absorber
Length	1, 880 mm
Width	735 mm
Engine Type	Single cylinder, 4-stroke
Cooling System	Air-cooled
Transmission	Automatic
Front Brake	Disc
