Battery recharge and starting
BATTERY RECHARGE AND START-UP SECTION
Specification
Desc./Quantity
1 Voltage regulator
2 Magneto flywheel
3 Automatic starter
4 Battery 12V-9Ah
5 Remote starter switch
6 Starter motor
7 Start up button
8 Brake light filament 12V-21W
9 Front and rear brake light button
10 Key switch
11 Main fuse 10A
12 Resistance 6,8 Ohm - 10W
Electrical system MSS Fly 50 4T
ELE SYS - 50
