Level indicators and enable signals section
START PERMISSIVE BUTTONS AND LEVEL INDICATORS
Specification
Desc./Quantity
1 Voltage regulator
2 Fuel gauge
3 Fuel level sender
4 Low fuel warning light 12V - 1.2W
5 Front and rear brake light button
6 Fuse 10 A
7 Battery 12V-9Ah
8 Brake light filament 12V-21W
9 Key switch contacts
MSS Fly 50 4T Electrical system
ELE SYS - 51
