- To replace the shock absorber remove the rear
cover and battery access flap to get and remove
the shock absorber/ chassis anchoring nut. Then
remove the shock absorber/engine anchorage
nut.
Refitting
- When refitting, tighten the shock absorber/chassis anchoring nut and the shock absorber/engine pin
to the prescribed torque.
Locking torques (N*m)
Shock absorber/engine pin torque 33 to 41 N·m Shock absorber/frame nut torque 20 to 25 Nm
Centre-stand
Sostituzione cavalletto completo
- Undo the screw marked in the figure.
- When refitting, secure to the prescribed torque.
Locking torques (N*m)
Centre stand screw 32 ÷ 40
Suspensions MSS Fly 50 4T
SUSP - 132
