Direct the jet of compressed air into the round groove between the threaded metal part and the ceramic
part of the inner electrode while turning the spark plug to allow removal of the oil in excess.
Hub oil
Check
Rest the vehicle on its centre stand on an even
surface.
- Unscrew the oil dipstick "A", dry it with a clean
cloth and reinsert it, screwing it in thoroughly.
- Pull out the dipstick and check that the oil level is
above the "middle" notch (dipstick with 3 notches).
For dipsticks with 2 notches, the oil level must re-
main in the lower half of the dipstick.
-Screw up the oil dipstick again and make sure it
is locked properly into place.
Recommended products
AGIP ROTRA 80W-90 rear hub oil
SAE 80W/90 Oil that exceeds the requirements of
API GL3 specifications
Replacement
Remove the oil filler cap/dipstick "A".
- Unscrew the oil drainage plug "B" shown in the
figure and drain out all the oil.
- Screw the drainage plug back and fill up the hub
with the required oil (about 100 cm³)
Maintenance MSS Fly 50 4T
MAIN - 32
