Fairing C
- Remove the central chassis cover.
- Remove the lateral fairings A and B.
- Remove the fairing by pulling it upwards.
Air filter
- Undo the three screws fixing the housing to the
engine crankcase;
- Loosen the hood clamp connected to the carbu-
rettor and disconnect it from the filter housing.
- Remove the clamp of the blow-by tube and take
it out.
- Push the housing upwards to free it from the ap-
pendages on the crankcase and remove it.
See also
Side fairings
Runner 125 - 200 Chassis
CHAS - 277
